HDMI Extender Over One CAT5E/CAT6(TCP/IP)

Specifications

HDMI Extender over one CAT5E/CAT6(TCP/IP)

I. Introduction

The HDMI Extender over ONE CAT 5E/6 is a tool for extending your HDMI signal over long distances to a compatible display. Instead of using expensive HDMI cables, your existing CAT 5E/6 cables/sockets can be utilized to perform advanced functions like transferring Deep Color (12 bits/color) video and digital audio, with a bandwidth up to 225MHz. The HDMI transmitter and receiver, over ONE CAT 5E/6 extender is your substantial HDMI extender tool. The HDMI Extender over ONE CAT 5E/6 also support IR re-transmitting, so you can control the Source which is 100 meters outside using the HDMI Extender.

II. Features

DC 5V~12V wide power supply.

HDMI 1.3, HDCP 1.1 and DVI1.1 compliant.

Support Deep Color up to 12 bits/color.

Support IR re-transmitting.

Uses one CAT5E/6 cable for data/DDC transmission.

Equalizes and recovers incoming TMDS data before re-transmitting it in optimal quality regardless of the incoming signal quality.

Cable testing showed that with 1080p resolution the HDMI input source can be 20meters away.

When transmitting a signal in 1080p resolution the CAT6 operating distance is 100 meters.

III. Package

HDMI Extender (Transmitter) ------------------------------------ 1PC

HDMI Extender (Receiver )--------------------------------------- 1PC

IR Transmitter ---------------------------------------------------- 1PC

IR Receiver -------------------------------------------------------- 1PC

5V DC Power Supply adapter ----------------------------------- 2PCS
