Polyimide Disc

Specifications

Polyimide Disc
1.Temperature Resistance:300Cenrigrage
2.Availability:Square,Rectangels,Donuts
3.Accept OEM
4.Diameter:14mm

Product  Name:Polyimide Disc

Polyimide film is a good H grade insulating material. It is widely used for insulation purpose in electrical appliances which are used in special environment. To use the polyimide film means reducing volume and weight of the electrical appliances while retaining the same output or increase the capacity without increasing in frame size. It can also prolong the service life of the electrical appliances and increase their reliability. Its long-term working temperature is over 200 °C.





The following properties of Polyimide Film ensure its good performance under extreme temperature or other conditions.

1.   Good property of insulation and mechanism

2.   Good temperature-resistant property, wide performance temperature range. It can be used under temperature from –60 °C to +250 °C for a long period and –269 °C to +400 °C for a short period without changing its electrical and mechanic properties.

3.   Good chemical stability. It resists most organic solvents.

4.   Excellent flame retardant property

5.   Good radian-resistant property
6.   Can be combined with many other materials. When combined with fluorine resin, its characters of wet and corrosion resistance are greatly improved.



Benefits of using Polyimide discs include

· These high performance Polyimide masking discs are suitable for powder-coating and electro-coating (E-coating) applications

· Polyimide discs offer a high chemical and abrasion resistance and are suitable up to +300c



Specifications



Disc Diameter	Discs per Roll	Color
14.0mm	2000	Amber
11.1mm	2000	Amber
10.0mm	2000	Amber
6.4mm	2000	Amber
9.5mm	2000	Amber
12.7mm	2000	Amber
15.9mm	2000	Amber
19mm	1000	Amber
25.4	500	Amber
38.1mm	500	Amber
41.3mm	250	Amber
50.8mm	100	Amber
101.6mm	100	Amber







Mechanical and Electrical Properties



Shenglognpan Offers

· Free samples on most Polyimide discs

· Low minimum order quantities on most Polyimide discs

· Great discounts for larger orders

· Free Polyimide disc technical advice from us

· Call now on 0086-21-58010397



Customers who bought this also bought

· Fibreglass Disc +260c

· Polyimide Masking Tape +300c

    Silicone Rubber Tape up to +315c





Package and Supply

The film is packed in rolls.

* Special Length available upon request

Width	Core Type	Core Size
7-20mm	Plastic	3 inch (76 mm)
20-1000mm	Paper	3 inch (76 mm)
