Custom Metal Uncoiling and Recoiling Slitting Machine for Coil Car, Uncoiler and Shearer

Details

Slitting line can do uncoiling, slitting and recoiling works, make coil steel to any needed width coil steel. It mainly includes coil car, uncoiler, shearer, correct device, slitting machine, scrap recoiler, tension unit, press unit, recoiler and coil car, hydraulic system, ect. It mainly used in coil or hot rolling carbon steel, silicon steel and all the other kinds of metal materials with surface spreading.
This line can be adjusted to do recoiling or dividing work to meet customers demands.
PLC system is used to select the information from every part of the line, centrally controlled. There also has speed self adjusted and keep memory after lost power supply function. So the line has efficient performance.

Model

YD-1-6-1600L

Coil thickness

0.2mm-6mm-22mm.

Slitting speed

Max.120m/min.

Loading capacity of the uncilier

Max6-35T

Coil I.D

460-560mm

Material of slitting blade

9CrSi

Precision

0.05mm

Main shaft Diameter

240-400mm.

Suitable material

Hot/cold-rolled/carbon steel/stainless.
