High frequency on-line PMR1000 POWER Castle Series Rack Mountable 6-10KVA

 Model

PC06RL

PC06RS

PC10RL

PC10RS

Capacity(linear Load)

6KVA/4800W

10KVA/8KW

Input Voltage Range

160V-285VAC

Frequency Range

45Hz~55Hz

Output Voltage

220/230/240V±3%

Output Frequency

50/60Hz±0.5Hz

Output Voltage Tolerance

<±5%(100% Load or without Load)

Distortion

<3%(Linear Load);  <5%(Non-linear load)

Output Waveform

True Sine Wave

Overload Capability

105%~130%, 10Mins; >130%:1Min.

Battery Voltage

192/240VDC(EXTERNAL)

Charge Voltage

220/275VDC

Charge Current

Standard model 1A ;Long back model 4A；

Battery Type

Sealed Maintenance-FreeLead-Acid

Batteries Q\'TY

12V×16/20Pcs

Standard Backup Time(Full Load/Half Load)

5/12Mins

Crest Factor

3:1

Noise( 1m )

<45db

<50db

LCD and LED

Utility, Inverter, Bypass, Battery, Load, Battery Mode, Frequency, UPS Fault Indicator

Transfer Time of AC to DC

Zero

Battery Low Voltage

168/210v2v

Charge Time

Charging up to 90% , ≤6Hours

Audible Alarm-Battery Discharge

Utility Failure, Beep/4s ；Battery Low, Beep/1s

EMC

50091 , 9254

UPS Abnormal

Continuous Beep and Red LED on

Output Short Circuit

Shutdown
