Home > Products > New product > resistance welder
resistance welder
- 10 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
Product Details
| Brand Name: | jiaoyang | Place of Origin: | China | Model Number: | GWC2500E |
Product Description
Mesh welding machine
Function features: motor drive
1. This kind machine is our latest developed reinforcing mesh welding machine.
2. The line wire and the weft wire are pre-straight and pre-cut. The line wire is feeding by the servo motor, pulling the wire net by the servo motor auto.
3. The welding power comes from the spring. It is easy to control the welding pressure.
4. The weft wire feeding from the multi hopper which capacity is 1.5t, more over ten times than the traditional hopper.
5. The new machine added the bear wire net and carries equipment that makes the working more convenience. The welding part is used the springiness input wire trunking that makes the welding copper use for long time.
6. 125KVA Transformer with water cooling system and separately welding controller.
7. This machine adopts synchronous control technique. The center-control and welding time
are composed of PLC program system. The input front-panel is touch screen, the operate is more intelligent and reasonable.
Main technical parameters:
|
Wire diameter |
5.0-12mm |
Line wire form |
pre-cut wire |
|
Weft wire distance |
50-300mm |
Weft wire form |
pre-cut wire |
|
Line wire distance |
100-300mm |
Rated voltage |
380V 50HZ |
|
net width (customized) |
2500mm |
Rated power |
125KVA X 12 |
|
Welding speed |
50 times/min |
Overall dimension |
24 X 6.0 X 2.65M |
|
line wire No. |
24 |
Max. mesh length |
12000mm |
Main technical parameters:
|
Wire diameter |
3-8MM |
Line wire form |
pre-cut wire |
|
Weft wire distance |
50-200mm |
Weft wire form |
pre-cut wire |
|
Line wire distance |
50-200mm |
Rated voltage |
380V |
|
grid width (customized) |
2500mm |
Rated power |
125KVA X 8 |
|
Welding speed |
60-80 times/min |
Overall dimension |
22 X 6.0 X 2.45M |
|
line wire No. |
48 |
Max. grid length |
12000mm |
Application:
The welded mesh can be used in the floor & wall reinforcing mesh in the building, reinforcing mesh in the tunnel, bridge and road.
