indoor cat6 lan cable

FOB Price

Negotiable / Piece

1000 Pieces(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:

lasun,CCB

Place of Origin:

China

Twisted Pair Cable (UTP), 4 pairs, Category 6, Solid, PVC

Specifications:
Meet ANSI/EIA/TIA 568-B.2-1 requirements Fire protection – IEC60332-1 (CM) The cable meets UL 1581 VW-1 fire safety standard

Description:
Unshielded copper cable, 4 pairs, category 6, solid Cable is used for indoor installation

Materials:
Conductive material: wire made of soft annealed electrolytic copper Conductor insulation: HDPE The cable jacket: PVC

Technical characteristics:
Conductor diameter: 0.57 ± 0.01 mm (23 AWG) Insulated conductor diameter: 0.99 ± 0.2 mm (0.038" ± 0.008") Outer cable diameter: 6.2 ± 0.2 mm (0.24" ± 0.008") Jacket thickness: 0.4 mm (0.015") Pulling strength: 130 N Minimum bend radius: 4 outer cable diameters Operating temperature: -20°C to +75°C (-4°F to +167°F) Weight per 1000 ft: 12.9 kg (28.4 lbs) Standard package: 305 m (1000 ft)

Electrical characteristics:
Frequency, MHz	RL	Attenuation, dB	NEXT, dB	PSNEXT, dB	ELFEXT, dB	PSELFEXT, dB
1.0	20.0	2.0	74.3	72.3	67.8	64.8
4.0	20.3	3.8	65.3	63.3	55.8	52.8
8.0	24.5	5.3	60.8	58.8	49.7	46.7
10.0	25.0	6.0	59.3	57.3	47.8	44.8
16.0	25.0	7.6	56.3	54.3	43.7	40.7
20.0	25.0	8.5	54.8	52.8	41.8	38.8
25.0	24.3	9.5	53.3	51.3	39.8	36.8
31.25	23.6	10.7	51.9	49.9	37.9	34.9
62.5	21.5	15.4	47.4	45.4	31.9	28.9
100.0	20.1	19.8	44.3	42.3	27.8	24.8
200.0	18.0	29.0	39.8	37.8	21.8	18.8
250.0	17.3	32.8	38.3	36.3	19.8	16.8

Conductor resistance at 20°C (68°F)	9.38 Ohm/100 m (2.9 Ohm/100 ft)
DC Resistance Unbalance	5%
Pair-to-Ground Capacitance Unbalance	330 pF/100 m (101 pF/100 ft)
Impedance 0.772-100 MHz	85-115 Ohm
Mutual Capacitance	5.6 nF/m (1.7 nF/ft)
Spark Test	2.5 kV
