cat6 ftp lan cable

FOB Price

Negotiable / Piece

1000 Pieces(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:

lasun,CCB

Place of Origin:

China

Twisted Pair Cable (FTP), 4 pairs, Category 6, Solid, PVC

Specifications:
Meets TIA/EIA/ 568-B.2 requirements Fire protection - CM The cable meets UL 444 UL 1581 fire safety standard

Description:
Shielded Copper cable, 4 pairs (separated), category 6, solid, with drain wire Application: Horizontal communication cable Cable is used for indoor installation

Materials:
Conductive material: wire made of annealed bare copper Conductor insulation: HDPE Shield: an aluminum-mylar (aluminum-polyethyleneterephthalate) tape is helically applied over the cable core, tape thickness - 0.001" (0.025 mm), width - 0.709" (18 mm); shield thickness - 0.016" (0.04 mm) Drain wire: tinned copper The cable jacket: PVC

Technical characteristics:
Conductor diameter: 0.57 mm (0.022") (23 AWG) Insulated conductor diameter: 1.09 +- 0.06 mm (0.043" +- 0.002") Drain wire diameter: 0.53 mm (0.021") Outer cable diameter: 7.2 +- 0.3 mm (0.276" +-0.012") Jacket thickness: 0.55 mm (0.028") Shield thickness: 0.04 mm (0.016") Minimum bend radius: 8 outer cable diameters Conductor elongation: 15% minimum Operating temperature: -20 - +75 (-4F - +167F) Rip cord has a breaking strength of 6.9 kg (60 N) Standard package: 305 m (1000.66 ft) Weight per 1000 ft (304.8 m): 16.8 kg (37.04 lbs)

Electrical characteristics
Frequency, MHz	RL	Attenuation, dB	NEXT, dB	PSNEXT, dB	ELFEXT, dB	PSELFEXT, dB
1.0	20.0	1.9	74.3	72.3	67.8	64.8
4.0	23.0	3.7	65.3	63.3	61.8	52.8
8.0	24.5	5.3	60.3	58.8	55.7	46.7
10.0	25.0	5.9	59.3	57.3	53.8	44.8
16.0	25.0	7.5	56.3	54.3	49.7	40.7
20.0	25.0	8.4	54.8	52.8	47.8	38.7
25.0	24.3	9.5	53.4	51.4	45.8	36.8
31.25	23.6	10.6	51.9	49.9	43.9	34.9
62.5	21.5	15.4	47.4	45.4	37.9	28.8
100.0	20.1	19.8	44.3	42.3	33.8	24.8
155.00	18.8	25.1	41.4	39.4	27.8	20.9
200.00	18.0	29.0	39.8	37.8	25.8	18.7
250.00	17.3	32.8	38.3	36.6	24.3	16.8

Max conductor resistance at 20°C (68°F)	9.38 Ohm/100 m (2.86 Ohm/100 ft)
Max Resistance Unbalance	5%
Max pair-to-ground capacitance unbalance	330 pF/100 m (101 pF/100 ft)
Characteristic Impedance at 0.772-100 MHz	100 +- 15 Ohm
Mutual capacitance	5.6 nF/m (1.7 nF/ft)
Spark Test	2.5 kV
