Band Knife Splitting Machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Shanghai

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

SUMON

Model Number:

S-420L

Product Description

Band Knife Splitting Machine

1.highly secure
2.highly precisious
tecting grinding geometric
4.digital display

Used for leather layer spliting of shoes,bags and cases,which is highly efficient and accurate.

1.The thickness of required leather sheets is adjusted by hand-wheel.

2.The thickness of leather can be displayed in the dial indicator.The minimum thickness can reach 0.15mm and the sheet precision is +-0.05mm

3.The knife griding abrasive wheel is adjusted by hand-wheel.The upper and lower abrasive wheels can be regulated seperately,and the band knife can restore position during the course of griding,which makes griding geometric shape remains unchanged.

4.When any gate or cover is not closed to right position,or the charging basket is overfilled,the dynamo can not start up and the red light will flash to aralm,which is highly secure.

5.Charging rate is adjustable as required and adopts digital display.

Main Technical Parameters
Motor Power		3.5KW
General Power		3.6kw
Power Supply Voltage		380V
Power Supply Phase		3-Phase
Max.Splitting Width		420mm
Frequency		50HZ
Splitting Thickness		0.15~8mm
Splitting Precious Allowance		0.1mm
Machine Net Weight		643kg
Package Weight		750kg
External Dimensions		160109123(cm)
Package Dimensions		170124142(cm)

Main Technical Parameters

General Power		1.9KW
Power Supply Voltage		380V
Power Supply Phase		3-Phase
Max.Splitting Width		320mm/400mm
Frequency		50HZ
Splitting Thickness		0.15~8mm
Splitting Precious Allowance		0.1mm
Machine Net Weight		425kg
Package Weight		485kg
External Dimensions		13560124(mm)
Package Dimensions		15068135(cm)
