Forming Plastic Extruder Machine For PVC Sheet , 9Cr18MoV 38CrMoAIA

Low Temperature Forming Planetary Extruder For PVC Sheet , 9Cr18MoV 38CrMoAIA

Summary:

It is very suitable for PVC material’s processing and production.

Planetary Extruder overcomes the liminations of single screw and twin screw extruders,has many outstanding advantages.

Due to the developing of the design and manufacturer,Planetary Extruder can gain the better performance, Accommodate more applications,and reduce the cost of equipment and products. Thereby obtains better economy.

Specifications:

1. Materials: 38CrMoAIA, 9Cr18MoV
2. Application:PVC

3. Depth of nitration case:0.5-0.8mm

4. Hardness of nitration: 950-1020HV

5. Fragility of nitration: Less than grade 1

6. Roughness of the surface:Ra 0.4um

7. Linearity of the screw:0.015mm

8. Chromium-plating layer thickness:0.03-0.08mm

9. The surface hard chromium plating hardness after nitrogenation:>=950HV

10. Guarantee: Common Nitrided: approx 2 years     Bimetallic : much longer life time

Features:

1) The \"PRE\", a series of planetary roller extruders, experiences rolling and extrusion in configuration that a planetary screw is inter-engaged at a centerof a main SCREW and BARREL which are screwed in a shape of helical gear at 45 degree.

2) The planetary screw revolves and rotates on its axis, in order to employ various resin.

3) The extruder is special and applied to various product and mass production.

4) In special, because the extruder supplies the rolling and extrusion through space of the inter-engagement, it may plasticize the resin at a low temperature.

5) Through the inter-meshing action of the toothed planetary roller system just one single revolution of the main spindle suffices to roll out the plasticmelt as many as 1, 100 times, ensuring optimum plastification, homogenization and dispersion.

6) The \"PRE\" is a low-temperature forming extruder which may produce produces without any change of properties owing to its low-temperatureforming and homogenizing.

7) Combined rolling and extruding action: Through the inter-meshing action of the toothed planetary roller system just one single revolution of the mainspindle suffices to roll out the plastic melt as many as 1, 100 times, ensuring optimum plastification, homogenization and dispersion.

8) Compared with other extruder designs, this system increases the contact surface of the melt by up to five times.

9) Low-cost formulation: The optimum heat-exchanging effect created by the large contact surfaces of the planetary roller system in conjunction withshort residence time of the melt helps to achieve a considerable reduction in formulation costs. Costly stabilizers and lubricants are reduced to a minimum.

10) Self-cleaning feature: Since all toothed components of the machine constantly inter-mesh, no residual material is left in the machine when changing over from one formulation to another. The system is change-over from one color to another, results in no more than 5kg of scrap.

Applications:

Planetary Extruder Mainly used in the production below:

1. Rigid PVC sheet calender line

2. PVC Card calender line

3. Soft PVC film calender line

4. PVC pelletizing line

5. Cables coating

Detail specification:

(1). Planetary roller section: main screw 1 pc; planetary roller 10 pcs, knife

plate 1 pc, gear tooth sleeve; And this section is jacket-designed, which

can get through by heating oil; The main screw is core-drilled, heated by

oil; And the head of machine is cooled down by water;

(2). Section of material feeding, jacket-designed, water cooling.

(3). Feeding motor power: 2.2 KW;

(4). Hard-toothed gear box, Chinese famous brand;

(5). Inverter motor, AC, 160 KW;

(6). Stainless steel hopper, capacity of 1000kg;

(7). Metal detector( brand of S + S) is equipped on the top of the hopper;

(8). Rotating speed of main screw: 0 – 60 rpm, speed is adjustable;

Competitive Advantage:

1) Better performance

2) Long usage life

3) Good production stability

4) Reasonable design

5) High precision
