Hydraulic Flying Shear Roofing Roll Forming Machine PLC Control Tile Press

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HRF		Place of Origin	China
Model Number	R35-1000

Product Description

Delivery Time:90
Certification:CE

High-Speed Flying Shear Panel forming machine Roofing Tile

Descrition:

1. R35-1000 panel forming machine is used in South America and North Amrica.We have engaged in designing and supplying the this machine since 2010 .With stable performance and good forming product,we gained good reputation from our customers .

We adopts 26 forming stations with Torri stands and 10T hydraulic decoiler and superonice sensor control to sychronize the speed between the roll forming machine and decoiler .The main machine power is 22kw ,Siemens motor made in China and the motor has the device to prevent against overheat .The rollers materials is 45#,quenched HRC48--52,chrome on the surface of the rollers.The main shaft material is 45# steel,fine processment,solid diameter 85mmThe whole machine frame is welded by I beam GB standard and milling on the sufrace to gurantee the levelling .We adopt non-stop cutting,also called “flying shear” with servo-motor control and the working speed can reach up to 45m/min and with cutting tolerance wthin 2mm Yaskawa servo motor made in Japan,4.4kwWe recommend 12m auto-stacker and 6m or 8m is available as well .The power supply requirements is 440v,60hz2ph or according to the customer’s local standardWe install the emergency stop at the cutter and coil entry point as well the yellow safety guard .

Applications:

IBR panel
IBR686 roofing tile
IBR sheet

Drawing:

1	Material thickness	mm	0.4-0.8mm Full hard,G550Mpa
2	Forming speed	m/min	45
3	Roll station	/	26
4	Main power	kw	2-11
5	Hydraulic power	kw	11
6	Way of cutting		Flying shear
7	Control system	/	PLC panasonic/omron/simens/mitsubishi
8	Drive	/	Chain drive
8	Decoiler		0T/15T hydraulic decoiler ( coil car as option)

Flowchart

Competitive Advantage:

1. We have experienced engineer who engaged in designing the roll forming machines for 10 years

2. We have complete after-sales service system and we guanratee all life of the machines maintaince .

3. We can gurantee in-time delivery and well-done packaging
