12 Cores Outdoor Telecom Cabinet , Telecommunication Enclosure

Delivery Time:15 days
Certification:ISO 9001:2008

12 Cores Outdoor Telecom Cabinet , Telecommunication Enclosure

FTTB Access box, Access Cabinet
1.Fiber storage capacity up to 12 cores, and network panel 6-48 ports
2.Used for FTTx installation
3.Using Spcc Cold Rolled Steel
4.Burglar-proof lock system

Quick Detail:

FTTB Access box, Access Cabinet, FTTx Cabinet

Grandway corridor integrated access cabinet is specifically designed for last sector of FTTH installation , the cabinet brings a flexible solution for safely containing optical converter,optical fiber terminal block and optical transmitter and other electronic equipments.
Grandway access cabinet is normally installed in the corridor of living building,.It equips with a strong venting system inside, the hermetic shell is designed according to CE standard. The cabinet contains various of batteries,electric power and all kinds of electric equipments.It has capacious space to contain power area,distributing&splicing area and equipment area. The cabinet meets the requirements of IP55 protection level.


Features:

Double-door design, convenient for installation and maintenanceAdopt 200L 110 High-frequency module, convenient for cable forming and maintenanceCapacious space for the installation of CATV equipmentFlexible configuration for clients\' choices, simple operation and easy for maintenanceFiber storage capacity up to 12 cores, and network panel 6-48 portsShutter design for cabinet window, in favour of the heat dispersing and venting of active equipmentsUsing Spcc Cold Rolled Steel material, and surface treatment of deareasing, rustproof, phosphoric spraying, exquisite design with precise dimension and craftsmanship.Posses voice frequency cable distribution and equipment power access safety socketBurglar-proof lock system

Ordering Information:

SPX2-C-AA-BB-CC-DD-EE

AA-Door Type	BB-Splice Tray	CC-Power Strip	DD-Power Sockets Standard	EE-Distribution Module
1 Single door	1 12 trays	1 3 sockets	1 US standard	1 RJ45 module
2 Double door	2 24 trays	2 6 sockets	2 UK standartd	2 Krone module
3 Others	3 Others	3 Others	3 EU standard	3 110 module
			4 Others	4 Others

Applications:

Used in many industry relative to network


Standard configuration:

Cabinet (Earthing Wire, lock, cable fastner and dust-proof cotton included), Power strip, Air switch, Splicing tray, distribution module bracket, Krone module, Accessories bag, wiring mounting bracket.


Optional configuration:

Surge protector(thunder protector), Fan, Heather, Temperature Sensor.


Advantages

1.Reliable sealing
2.Water-proof and Damp-proof
3.Easy Installation
4.Compact Structure
5.Mainly customers: CMCC,ZTC ,HUAWEI
