High Temp Overflow Yarn Dyeing Machine For Dyeing Cotton Yarn

High Temp Overflow Yarn Dyeing Machine For Dyeing Cotton Yarn

This machine is suitable for cotton , wool and artificial wool , acrylic yarn. Yarn can be completed puffing , scouring , bleaching , dyeing , soft multiple and other dyeing and finishing process .

The distance between hanging yarn bars is adjustable to adaptto dye different length of yarn.

With precise and reversing controller to automatically transform the circulating direction of dye solution , to ensurethat the yarn levelling .

Circulation water pump is well designed .

This model can be used with two series machines in order toreduce differential cylinder process.

standard structure.

The parts contacted with dyeing liquid is made of high quality high corrosion of stainless steel.

Equipped with two sets of yarn bar

Guide plate uniform make dye solution inside the machine cycleuniform

Equipped with high quality stainless steel feed pump.

Barrel have mixing , feeding material , recoil , the liquid and cleaning device

Safe and convenient sampling device.

standard structure

Full automatic , semi-automatic computer control

Full automatic control of color bucket

The main pump USES frequency conversion control

Quantitative loading system

technical parameters

The highest working temperature : 98 ℃.

Heating rate : 20 ℃- 98 ℃, about 30 minutes ( steam pressure 6 kg /cm²).

Cooling rate : 98 ℃ -80 ℃ ,about 15 minutes ( cooling water pressure 3 kg /cm² ).
