Male SATA Connector , Electronic Power Connectors 13mm Pitch for automobile
USD $ 0.001 - $1
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Single / Double Row Wire Harness Assembly 3.0mm pitch for automobile
-
3.0mm Automotive Wire Harness Assembly , Single / Double Row Car Wiring Harness
-
Automotive 1.0mm Pitch Wire Harness Assembly 2 pin - 24 pin , Right / Vertical Angle
-
6.2mm Pitch Cable And Wire Harness Assembly for Office Equipments
-
Female & Male 1mm LED Light Bar Connector Wire to board 2 pin - 24 pin
-
1mm Pitch (039\") LED Light Bar Connector , Wire to board connector 15 pin
Product Details
| Brand Name | SWB | Place of Origin | China | |
| Model Number | 1301 Series |
Product Description
Certification:ISO9001/SGS/UL/RoHS/Reach
Electronic Power Connectors 13mm Pitch for automobile
Specifications:
|
Product Name |
SATA Connector |
|
Product Series |
Power Connectors |
|
SWB Part Number |
1301 |
|
Gender |
Male |
|
Pitch |
13mm |
|
No. of Rows |
1 |
|
No. of Contacts |
2 |
|
Orientation |
Straight/right angle |
|
Contact Material |
Phosphor Bronze |
|
Contact Plating |
Gold Flash |
|
Plastic Material |
PBT UL 94V-0 |
|
Plastic Color |
Natural |
|
Current Rating |
1.5A AC/DC |
|
Voltage Rating |
30V AC/DC |
|
OperatingTemp. Range |
-35℃~+85℃ |
|
Contact Resistance |
30mΩ Max |
|
Insulation Resistance |
1000MΩ Min |
|
Withstanding Voltage |
500V AC/minute |
|
Wire Range |
AWG#18~22 |
Competitive Advantages:
Reputation Best Re-Sale and After-Sale Service Small Orders Accepted Free SamplesContact Us
