Automatic High Speed Plastic Compound Water Container Cap Making Machine

Automatic High Speed Plastic Compound Water Container Cap Making Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Other, Food, Machinery & Hardware
Driven Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Other, Food, Machinery & Hardware
Driven Type Electric
Automatic Grade Automatic
Voltage three-phase380v,
Power 13.5kw
Packaging Type Bottles
Packaging Material Plastic
Place of Origin Shanghai, China
Brand Name HG
Model Number QY100-2
Dimension(L*W*H) 3900mmX1340mmX1500mm
Weight 2412kg

Specifications

1.Produce PVC/Aluminun-plastic material
2.120 pcs /min
3. Stainless steel devices
4. Automatic running
5.Easy operation

Application:

The cap making machine is suitable for making PVC caps for buckets.



Automatic High Speed plastic compound water container Cap Making MachineAutomatic High Speed plastic compound water container Cap Making MachineAutomatic High Speed plastic compound water container Cap Making Machine



Technical Parameters:



catalog of Technical Parameters

1-1 Output (depends on design of glue cap and quality of material)

1-2 Specification of Glue Cap

1-3 Main Materials (PVC Thermal Shrink Film and Aluminum Compound Material)

1-4 Top Cap Material (Aluminum Foil or Aluminum Plastic Compound)

1-5 Top Cap Material (PVC Hard-blank Plastic Film)





1-1Output (depends on design of glue cap and quality of material)
1-1-1 Design production capacity of the machine         100 PCS/min
1-1-2 Normal production capacity of the machine         90 PCS/min



1-2 Specification of Glue Cap
1-2-1 Top diameter              55mm~63mm
1-2-2 Bottom diameter          Maximum 65mm
1-2-3 Height                     55mm ~70mm
1-2-4 Taper                     1.5°~5°

1-3 Main Materials (PVC Thermal Shrink Film and Aluminum Compound Material)
1-3-1 Diameter of coil center                           3" (76mm)
1-3-2 Outer diameter of coiled material                   Maximum 400mm
1-3-3 Width of coiled material                          Maximum 210mm
1-3-4 Thickness of PVC coiled material                0.055 mm ~0.08mm



1-4 Top Cap Material (Aluminum Foil )
1-4-1 Diameter of coil center                       3" (76mm)
1-4-2 Outer diameter of coiled material Maximum      280mm
1-4-3 Width of coiled material Maximum             60mm
1-4-4 Thickness of coiled material                   0.04mm~0.08mm



1-5 Top Cap Material (PVC Hard-blank Plastic Film)
1-5-1 Diameter of coil center                      3" (76mm)
1-5-2 Outer diameter of coiled material Maximum      280mm
1-5-3 Width of coiled material Maximum             40mm
1-5-4 Thickness of coiled material                 0.06mm~0.08mm



Size of Machine: 3900mmX1340mmX1500mm
Weight of Machine: 2412kg
Power: three-phase380v, 13.5kw
