Electronic Universal Testing Machine with Hydraulic Pressure Fixture
- 360 Set / Sets per Month
- Qing Dao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Product Details
Brand Name: | HRJ | Place of Origin: | China | Model Number: | WDW-Y50/Y100 |
Power: | Electronic | Usage: | Universal Testing Machine |
Product Description
Electronic Universal Testing Machine with Hydraulic Pressure Fixture
1 Introduction:
1) tensile, compression, bending, torsion, shearing testing and researching with variety of metal, nonmetal material and composite material under room temperature.
2) sample of thin plate, panel, belt, foil, flat bar, wire, bar, proximate matter, pipe, sheet, square, round, rectangle, and annular shaped, cast iron, nonmetal alloy of cast iron, pipe section, proportional and non-proportional(index: k= 11.3 or 5.65), fully wall thickness of longitudinal and horizontal peeling strip, rectangle and round section.
3) tensile, compression and bending test with variety of rubber, plastic, film and other nonmetal material
4) test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam.
5) test with textile, food, medicine, cosmetic, biological material.
6) tensile, peeling and welding strength test with electronic component.
7) test with wooden, paper, film production and other nonmetal material.
2 Standard
1) ASTM E8 / E8M - 16a Standard Test Methods for Tension Testing of Metallic Materials
2) BS EN ISO 6892-1:2016 Metallic materials. Tensile testing. Method of test at room temperature
3) ASTM E9 - 09 Standard Test Methods of Compression Testing of Metallic Materials at Room Temperature
4) ASTM D695 - 15 Standard Test Method for Compressive Properties of Rigid Plastics
5) ASTM D4018 - 17 Standard Test Methods for Properties of Continuous Filament Carbon and Graphite Fiber Tows
3 Specification:
No. | Item | Specification |
1 | Load capacity | 50kN/100kN |
2 | Accuracy | ±0.5 |
3 | Measurement range | 0.4% -- 100%FS |
4 | Relative error of indicated value | ±0.5% |
5 | Resolution of load | 1/±300000F.S(resolution is not changed in full scale) |
6 | Range of deformation | 0.2% -- 100%FS |
7 | Relative error of deformation | between ±0.5% of indicated value |
8 | Resolution of deformation | 1/±300000 of Max. deformation |
9 | Relative error of indicated displacement | between ±0.5% of indicated value |
10 | Resolution of displacement | 0.015μm |
11 | Range of force speed | 0.005 – 5%FS/S |
12 | Relative error of force speed | between ±1% of set value |
13 | Range of strain speed | 0.02 – 5% FS/S |
14 | Relative error of strain speed | speed ≦0.05%FS, between ±2% of set value speed ≧ 0.05%FS, between ±0.5% of set value |
15 | Range of crosshead speed | 0.001 – 600mm/min (customized 2m/min&80in/min – 25m/min & 1000in/min high speed tensile testing machine) |
16 | Relative error of crosshead speed | speed ≦0.01mm/min, between ±1% of set value speed ≧ 0.01mm/min, between ±0.2% of set value |
17 | Range of constant force, strain and displacement | 0.5% -- 100%FS |
18 | Precision of constant force, strain, displacement | set value is ≦10%FS, between ±1% of set value. set value is ≧10%FS, between ±0.1% of set value |
19 | Crosshead stroke | 0 – 1400mm |
20 | Test span | 610mm |
21 | Clamp mode | hydraulic auto clamp |
22 | Size of load frame(LHW) | 1100*720*2200mm |
23 | Size of hydraulic cabinet(LHW) | 1200*900*1100mm |
24 | Power | 3.5kw |
25 | Voltage | 380±10%, 50Hz |
26 | Weight | 1400kg |
