2ply B flute corrugated cardboard carton production line

2Ply Single Face Corrugated board Production Line

Characteristics

1. Hydraulic mill roll stand with Expanding Chuck,

    The clamped scroll: Φ1500mm ×(800~1600)mm

2. BA-150 Auto Splicer.

    High precision, tensile force wheel is controlled by electron control to obtain stable splicing

3. Automatic inner vacuum cassette single facer.

    Diameter of the corrugated Roller is Φ360mm,made of material 48CrMo alloy metal

4. Pre-conditioner, preheater

    Diameter of the heating barrels are Æ900 mm.

    There are two guide rollers over the top of the pre-heater big barrel (with polishing surface),

    one is fastness, another rotate around the big barrel by electro-motion adjustment.

5. Single layer span bridge, Germany structure of conveyor.

    At the bottom of the bridge, equipped with relevant illumination, be convenient to operate.

6. PLC control rotary shear cut-off and convey stacker

    Shearer Cut-off is a new advanced equipment for producing B,E, F…FLUTE single face corrugated cardboard equipped in production line, also can cut base paper(such as white cardboard, kraft paper) into sheets.

7. Single face rewinder

    Equipped 4 sets of round blades slitting, 1-3 rolls after rewind.

    The caustic dissolving tank is made of Stainless Steel. The system is devised with agitating unit.

Wind-Suction Tension Device on Bridge

Preprinted single face corrugated board, form our Ecuadorian client

Our engineers are available to serve overseas

We attended to the trade fairs all over the world

FAQs

1Q: Are you the manufacturer?
A: Yes, we are the professional manufacturer.

2Q: Where are your factory located in ?
A: Our factory located in Zhaoqing city, Guangdong, China

3Q: Where is the nearest airport of factory ?
A: The nearest airport is Guangzhou Baiyun International airport. It take 1.5 hours from Guangzhou to Zhaoqing factory by car. We are glad to pick you up at the airport.

4Q: What is your business process?
A: Talk about requirements, confirm details, sign a sales contract, pay for deposit, arrange production, test machines, buyer pay for the balance payment, arrange shipment.

5Q: How to control machine quality ?
A: All material are environmental protection,non-pollution
  We have professional technicists to supervising to production
  Our professional department to examine about every production process

6Q:What can you do if the machine broken?
A: The warranty period is 1 year. If the broken parts can't repair, we can send the new parts to replace the broken parts for free, but you need to pay the freight. After warranty period, we can negotiate to the problems, and we supply the technical support for the whole life of the equipment.
