Wood finger jointer core veneer composer machine

FOB Price

USD $20000 - $40000 / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port Qingdao China
Payment TermsT/T L/C D/P D/A PayPal Other
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	METRO	Place of Origin	China
Model Number	PBJ-4X8	Certification	ISO, CE
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	1 year
Weight	5800Kgs	Dimension(LWH)	1200026002500mm
Voltage	380V/415V	Condition	New
Power(W)	26kw	Max Working Height	2300mm
Max. Working Width	2600mm	Spindle Speed	0-35m/Minute(Adjustable)

Product Description

Core veneer composer for shuttering plwoodThis machine is mostly used lateral composing, automatic rolling, automatic laying of the veneer with thickness of 1.0-3.6mm (commonly known as sandwich skin),in the production of laminated wood, LVL, multilayer board, flooring substrate, furniture board, plywood, container board, melamine board, block board. In the area of international and domestic plywood production process ,it is the first program designer and implementer using the rolled veneer, change the traditional manual planking process, to achieve the plywood planking automation, continuous and economizing

Machine Parameters:

machine model	PBJ-4X8
Whole machine	Length	10000mm
	Width	2600mm
	Height	2300mm
Drive motors	Front drive motor	3Kw x 1set
	Back drive motor	3Kw x 1set
	Front cutting knife	3Kw x 1set
	Back cutting knife	3Kw x 1set
	1# Belt conveyor motor	1.5kw x 1set
	2# belt conveyor motor	1.5kw x 1set
	Lifting motor of stacker	3Kw x 1set
Glue tank	Glue thread	4Kw
Glue tank	Glue point	4Kw
Total motor power	26Kw
Electrics	AC Contactor	Schineider
	PLC	DELTA
	AC conditioner	GREE
Cutting knife length	1400mm
Working thickness range	1.2-3.5mm
Working capacity	250-300sheets of 4x8Ft
Machine installation size	14000mm Length x 4000mm width
Machine weight	5800Kgs
