Glass Loading Table

Henan Yuanbei Glass Machinery Co., Ltd.
Glass Loading Table thumbnail-1
Glass Loading Table photo-1
US$ 1,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
JINGLING
Place of Origin:
Anhui, China
Model Number:
JL-QSP-4028
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name JINGLING
Place of Origin Anhui, China
Model Number JL-QSP-4028
Certification CE
Machine Type Glass Loading Machine



JL-QSP-4028 Glass Loading Table



Characteristic



-          Mn bridge steel (Q345A ), perfect surface treatment



-          High quality imported NBR material vacuum chuck, Japan SMC vacuum switch



-          Touch screen operation



-          A key reset function



-          Alarm system for safety and wrong operation



-          Flat four-bar linkage lift structure (much more stable than guide screw lift)



-          High precision and wear-resisting gear and chain, full-enclosed chain



-          Imported PU material wheels



-          Germany technology vacuum pump 1.5Kw







Mechanical parts







Name

Brand

Transmission Motor

CBG (TaiWan)

Vacuum Pump

JoySun (Shanghai)











Electric parts:







Name

Brand

PLC

OMRON JAPAN OR SIMENS GERMANY

Touch screen

HITECH

Converter

TECO

Solenoid valve

AIRTAC







Technical parameter:







Model

Max. glass size

Thickness

Dimensions (L*W*H)

Structure

Air pressure

QSP-2620

2440*1830mm

2~19mm

3560*2200*900mm

Mechanical

0.6~0.8MPa

QSP -3725

3660*2440mm

3~19mm

4680*2600*900mm

Mechanical

0.6~0.8MPa

QSP -4028

4000*2800mm

3~19mm

5000*2850*900mm

Mechanical

0.6~0.8MPa

QSP -5033

5000*3300mm

3~19mm

5400*3000*900mm

Mechanical

0.6~0.8MPa

QSP -6033

6000*3300mm

3~19mm

6430*3340*900mm

Mechanical

0.6~0.8MPa







 Glass Loading TableGlass Loading TableGlass Loading TableGlass Loading Table
