Aluminum windows machine Aluminum profile cutting saw/ Double head cutting saw machine
Contact person: Lucy
0086-151 6904 2082
Double head Precision Cutting Saw machine
1.The main spindle is manufactured by the specialized manufacturer. And the imported linear bearing motional pair is used to move the head horizontally. The blade feeding is hydraulic damping drive with large processing range. And the maximum cutting length is 4200mm. The cutting angle is 90, 45 and 22.5. The cutting length and other parameters are digital display.
Power Supply | 380V 50Hz |
Input Power | 4.4KW |
Working Air Pressure | 0.5-0.8MPa |
Blade Rotational Speed | 3100r/min |
Saw Blade Specification | D=500mm??d=30mm |
Cutting Length | 380-4200mm |
Cutting Angles | 90,45??22.5?? |
Outside Dimension | 5685*1750*1990mm |
Weight(about) | 1800Kg |
We have also other machine supply.
Machine style | Machine names | Machine mould |
Aluminum windows and doors machinery | Cutting saw machine | CNC mould |
Digital Precision mould | ||
Precision mould | ||
Corner Combining machine | Horizontal Four corner mould | |
Vertical four corner mould | ||
Two head mould | ||
Single head mould | ||
Corner connector cutting saw | Automatic mould | |
Semi-Automatic mould | ||
End milling machine | ||
Copy routing machine | ||
Combination drilling machine | ||
Pressing machine | ||
Profile tenon milling machine | ||
Bending machine |
3.Contact person: Lucy
Mobile: 0086-15169042082
Warmly welcome to inquiry, thanks in advance. .
