1.6ton mini crawler excavator

Name: 1.6ton mini crawler excavator
Brand: MAP
Availability: InStock

FOB Price

USD $30,000 - $40,000 / Unit

1 Unit(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:	MAP	Place of Origin:	Shandong, China	Model Number:	MAP15-7
Certification:	CE	After-sales Service Provided:	Engineers available to service machinery overseas	Condition:	New
Machine Weight:	1550kg	Moving Type:	Crawler Excavator	Rated Speed:	0-2km/h
Max Digging Radius:	3530mm	Maximum Digging Depth:	2100mm	Maximum Digging Height:	3200mm
Bucket capacity:	0.05 M3	Operating Weight:	1550KG

MAP16 Mini Crawler Excavator Detailed Technical Data:

weight	1600kg
Bucket
Bucket Width	460mm
Bucket capacity	0.05m3
Engine(water cooling)	Chinese LAIDONG 380
Power/ Speed	15.5/2400 kw/rpm
Overall dimensions
Length	3800mm
Width	1080mm
Height	2000mm
Pear part Rotary radius	1350mm
Mini clearance	210mm
Performances parameter
Driving speed	0-2 km/h
Swing speed	0-11 rpm
Climb capacity	40%
Max traction force	15 kn
Operation range
Max excavation height	3200mm
Max excavation depth	2100mm
Max unceding height	2280mm
Max excavation radius	3530mm
Hydraulic radius
System rated working pressure	18 Mpa

1.5ton crawler excavator:
