VMC640L linear guideway CNC milling machine price with good precision
USD $19,000 - $50,000
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- Shanghai Port
- T/T Credit Card
You May Like
-
XH7140 with whole cover precision CNC milling machine with CE
-
VMC600L Linear guideway 4 axis cnc milling machine
-
VM850L high speed linear guideway CNC milling machine
-
XK1860 cheap 4 axis vertical CNC Milling Machine with CE
-
XK7140 precision vertical hobby CNC milling machine 5 axis price with CE
-
XH7132 CNC milling machine with ATC for sale
Product Details
| Brand Name: | WMT | Place of Origin: | Anhui, China | Type: | Vertical |
| Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 13 months |
| Weight: | 4100kgs | Dimension(L*W*H): | 2200x2100x2550mm | Voltage: | 380V |
| Condition: | New | Power(W): | 5.5kw |
Product Description
Specification(VMC640L cnc milling machine price) CNC MILLING MACHINE PRICE
| SPECIFICATION | VMC640L | |
| Worktable | worktable size | 400×900mm |
| Max load of worktable | 350kgs | |
| T-slot size | 3×18 | |
| T-slot pitch | 100mm | |
| Travel | X/Y/Z-axis travel | 640/400/500mm |
| distance from column to spindle center | 476mm | |
| distance from table surface to spindle nose | 120-620mm | |
| Spindle | Spindle hole taper | BT40 |
| Spindle power | 5.5kw | |
| Max spindle speed | 8000/10000rpm(spindle oil cooler) | |
| Feed | Max feed speed | 6000mm/min |
| Rapid feed speed(X/Y/Z) | 30/30/24m/min | |
| Accuracy | Positioning accuracy(X/Y/Z) | ±0.01mm |
| Re-positioning accuracy(X/Y/Z) | ±0.005mm | |
| Other | Packing size | 2200×2100×2550mm |
| Net weight | 4100kg | |
Machine details:
Guarantee Terms:
Complete service by free of charge within 13 months after B/L date Technical service will be given forever at any time. Any questions during operation, can contact us freely by email, or contact on line by Skype, WhatsApp, etc. Also can talk face to face during fairs. You will get response within 20 hours.
