CK50L CNC Milling Cutting Machine Lathe Machine Price

FOB Price

USD $22,900 - $31,900 / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port Qingdao Port for CK50L CNC Milling Cutting Machine Lathe Machine Price
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

1）The machine are the slant bed cnc machine tools of higher speed, higher precision and higher reliability.

2）The spindle is in unit structure, the motion given by the frequency motor will be transferred to the spindle through synchronous belt, thus we can get the highest speed.

3） The hydraulic chuck is employed for clamping the work piece, which makes the clamping more convenient, accuracy highly improved and operating strength saved.

4）Machine adopts 45 degrees oblique slide saddle and linear guide rail, stronger in rigidity, faster in feeding speed and easier in chip removal.

5）The X and Z axis screws are in the middle of the carriage, well-distributed in force, smooth in movement, higher in speed.

6） The tools changed quickly, stably, precisely and chooses tool from the nearest.

7） It is easy to operate hydraulic tail stock. Fully shield machine house does not leak oil and water, green and beautiful.

Item	Unit	CK50L
Max. swing over bed	mm	500
Max. swing over slide	mm	320
Max. processing length	mm	550
Max. cutting dia.(disc type)	mm	420
Max. bar dia.	mm	51
Spindle speed	rpm	2500
Spindle nose ISO form		A2-6/8
Thru-hole dia.	mm	66/82
Chunk dia.	mm	250(10")
Motor power	kw	5.5/7.5/11
Body structure		45° integrated
X axis travel	mm	260
Z axis travel	mm	550
X/Z axis rapid speed		24/24
Type		100-8T
Tool size	mm	25*25
Tailstock sleeve dia.	mm	75
Tailstock sleeve travel	mm	100
Tailstock sleeve taper		MT5
Processing precision		IT6
Repositioning precision	mm	X:0.006, Z:0.01
Roughness		Ra.≤1.25
N.W	kg	3500
Dimension	mm	3100X1800X1800

Products Show

Our company

Products series

Customer Photo

Packing & Delivery

Contact me

FAQ

Do you have after sales support?

A: Yes, we are happy to give advice and we also have skilled technicians available.

We need your machines running in order to keep your business running.

Q: What is your terms of payment ?

A: 30% T/T in advance, balance before shipment or irrevocable 100% L/C at sight.

Q: Do you have a warranty on your machines?

A: One year warranty excluding electrical components.
