Home > Products > CNC Vertical Machining Center > Best Sale Small CNC Vertical Machining Center VMC Machine Price

Best Sale Small CNC Vertical Machining Center VMC Machine Price

FOB Price

USD $10,900 - $29,500 / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port Qingdao Port for Best Sale Small CNC Vertical Machining Center VMC Machine Price
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:	HUNK	Place of Origin:	Shandong, China	Type:	Vertical
Certification:	ISO9001 CE	Warranty:	13 Months
Weight:	2500kg	Dimension(LWH):	185018001900mm	Voltage:	380V/220V
Condition:	New	Power(W):	3.7kw

Product Description

Application

It can complete the drilling, milling, boring, reaming, expansion, and other rigid tapping process. so it is suitable for many varieties, medium and small batch production. It can finish the processing of complex, high precision parts. It can be matched the four rotary shaft , in order to meet the requirements of special parts.

Product Description

Technical Parameter

Item	Unit	VMC460L
Table Size	mm	800×300
Load Capacity	kg	200
T Slot		3-14X80
X-axis Travel	mm	460
Y-axis Travel	mm	320
Z-axis Travel	mm	460
Distance from Spindle Center to Table	mm	90-550
Distance from Spindle Center to Column Slide Way	mm	395
Tool Shank		BT30/BT40
Spindle Speed	rpm	10000
Spindle Motor Power	kw	3.7
Max. Diameter of Tool	mm	φ80/φ120
Max. Length of Tool	mm	200
Max. Weight of Tool	kg	6
X/Y -axis Rapid Moving Speed	mm	10000
Z-axis Rapid Moving Speed	mm	10000
Feed Rate	mm/min	1-4000
Positioning Accuracy	mm	±0.012
Repeated Positioning Accuracy	mm	±0.007
Out Dimension	mm	1850X1800X1900
Machine Weight	kg	2500

Testing & Delivery

About us

Contact me

FAQ

Q:Do you have after sales support?
A: Yes for Sure.
1.24 hours on Internet and Telephone, free instruction and problem solving.
2. Free training how to use.
3. User-friendly English manual or operating video for machine using and maintaining.
4. on-the-spot training and installation can be met if required.

Q: How can I choose the most suitable machines?
A: Please tell me your specifications, we can choose the best model for you, or you can choose the exact model. You can also send us the products drawing, we will choose the most suitable machines for you.

Q: Are you factory?
A: Yes, we are. Supply to you product with high configuration and perfect service at competitive price.
