Horizontal disc diatomite filter machine
1,Brief introduction:
It is made with excellent stainless steel , simple structure, easy operation,
maintenance and low cost, filter is of good quality and stable performance,
use the hand wheel mechanical compaction;Under the filter group moved,
can set wine pans ccording to user requirements ,
which is conducive to environmental health, and minimize loss of wine!
2, Spec.
Items | Parameter data | ||
Disc number(piece) | 20 | 15 | |
filter area(m2) | 4 | 3 | |
maximum operating pressure(MPa) | 0.5 | 0.5 | |
power consumption(KW) | 5.5 | 4.37 | |
sterilization temperature(°C) | 100 | 100 | |
flow reference(hl/H)
| Fruit wine(grape wine) | 20-40 | 10~30 |
| Fruit juice | 10-18 | 8~15 |
| Syrup | 10-15 |
|
| Sauce | 7-13 |
|
| Vinegar | 7-12 |
|
| Tea juice | 40-60 |
|
| Wine | 40-60 |
|
Dimension | Height | 1800 |
|
| L*W | 2400*1200 | 1800*1000 |
Weight(kg) | 1150 | 800 | |
3,For more details
