Home > Products > Self-Priming Pump > Chinese Factory High Quality Self-suction Pump Electric Water Pump

Chinese Factory High Quality Self-suction Pump Electric Water Pump

Name: Chinese Factory High Quality Self-suction Pump Electric Water Pump
Brand: BAQIU
Availability: InStock

FOB Price

USD $13 - $35 / Piece

100 Pieces(Min.Order)

Supply Ability 30000 Piece / Pieces per Month
Port NINGBO
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:	BAQIU	Place of Origin:	Zhejiang, China	Model Number:	PS126 vortex water pump
Power:	Electric
Usage:	Water	Theory:	Vortex Pump	Standard or Nonstandard:	Standard
Structure:	Single-stage Pump	Pressure:	High Pressure

Product Description

Chinese Factory High Quality Self-suction Pump Electric Water Pump

Model	Power		Inlet/Outlet (Inch)	Max.Flow (L/min)	Max.Head (m)	Packing demension (mm)	N.W
Model	Kw	Hp	Inlet/Outlet (Inch)	Max.Flow (L/min)	Max.Head (m)	Packing demension (mm)	Kg
P-130(AUT)	0.37	0.5	1''	35	28	205X210X280	10.4
PS-126	0.37	0.5	1''	36	33	280X185X265	9

1.Pump material

Pump Body: Cast Iron

Impeller: Brass

Motor bracket:Aluminum

Shaft with rotor:Stainless Steel or Cs45#

Mechanical Seal: Ceramic-Graphite

Copper winding

2. Operation Conditions

Max.Liquid temperature up to 40C

Max.Ambient temperature up to 40C

Max.suct:+9m continuous duty

3.Pump motor

2-pole induction motor:50Hz/60Hz

Insulation:Class B

Protection:IP44

With capacitor and thermal overload protection

4.Application

These pumps are suitable for handing clean water not containing abrasive particles and fluids which are not chemically

aggressive to the pump components.Reliable,compact,economical and simple to use.They are particulary suitable for

domestic and industrical applications such as water supply for recirculation in air conditioners and refrigerators,

industrial water uses in general.And the automatic distribution of water from surge tanks,watering gardens,lifting water

from tanks or wells down to 9m depth.The pump is supplied with check valve on the suction side so that no foot

valve is required.

Work shop area

Company Information

BAQIU Company Introduction

1)Taizhou BAQIU electrical and mechanical Co.,LTD which located in the home two of chinese water-Daxi,

Wenling China.We are integratd manufactural factory.

2)Our major productions are all kinds of water pumps.Based on excellent products and good reputation,they

have won favorable views from customers both at home and aboard and passed some domestric.

3)Our products are well sold in more than twenty province and cities in China,and exported to America,Europe,

Australia and Southeast Asia etc.

4)Quality always stands the first and honest is our concept.We provide reasonable price,punctuality and satisfying

service.We sincerely welcome all the friends from the world to join in us and develop together.
