Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > 60HZ X Engine 25kva Diesel Generator
US$ 1,999 - 3,899
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
SDS
Place of Origin:
Fujian, China
Model Number:
SDG-X20S3
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
60hz X Engine 20kw Super Silent Diesel GeneratorUS$ 999 - 2,999MOQ: 1 Set -
50HZ X Engine Super Silent 25kw Diesel GeneratorUS$ 2,500 - 3,500MOQ: 1 Unit
-
50HZ X Engine 20kw Silent Diesel Generator SetUS$ 1 - 2MOQ: 1 Unit
-
50hz X Engine Silent Diesel Generator 13kwUS$ 1 - 2MOQ: 1 Set
-
50hz 10kw Silent Diesel Generator SetUS$ 999 - 2,199MOQ: 1 Unit
Brand Name
SDS
Place of Origin
Fujian, China
Model Number
SDG-X20S3
Rated Current
36.09A
Output Type
AC Three Phase
Speed
1500RPM
Frequency
50HZ
Rated Voltage
380V
Rated Power
20KW
Product Description
60HZ X engine 25kva diesel generator
1)X engine+S alternator copy
2)68db@7m
3)Good performance
Important Features:
12 months warranty
X engine, the most cost-effecive type engine, very good performance
Light weight &compact in structure
Brushless alternator, in accordance with IEC60034
50 Litre top tank to avoid fuel leakage
Deepsea702 controller applied
Rugged, closed water cooled, 4-cycle direct injection diesel engine.
Best Quality AVR
100% copper wire
ATS is available
| Generator Specification: | ||
| Frequency | 50Hz | 60Hz |
| Rated Power KW | 16KW | 20KW |
| Max power KW | 17.6KW | 22KW |
| Rated voltage (V) | 230/400 | 240/416 |
| Rated current A | 28.87 | 34.7 |
| Rated speed r/min | 1500 | 1800 |
| Starting Mode | 12V Electric | |
| Feul tank capacity (Liter) | 44L | |
| Continuous operational time(hrs) | 7 hrs | |
| Noise level(dB(A)/ 7m) | 69 | 70 |
| Dimension L.W.H.(mm) | 1750*750*800 | |
| Net weight (kg) | 480 | |
| Loading Capacity | 14pcs/20'FCL, 40pcs/40'HQ | |
| Engine Specification: | ||
| Engine Model | 4DW91-29D | 4DW91-38D |
| Manufacturer | XC | |
| Engine Type | Closed water cooled, in line, 4-cylinders, 4-cycle, direct injection, | |
| Air Intake Type | Natural | |
| Bore*Stroke | 90*100 | |
| Displacement(L) | 2.546 | |
| 12h Power kw(ps) | 21/1500r/min | 28/1800r/min |
| Fuel Consumpion g/kw.h | ≤235 | |
| Compression ratio | 17:1 | |
| Starting Motor (V-KW) | 12V-3.5KW | 12V-3.5KW |
| Charging alternator(V-W) | 14V-500W | 14V-500W |
