Tobee® 14/12ST-AHR Rubber Slurry Pump

Size: 14" x 12" Capacity: 1152-2520m3/h Head: 13-44m Speed: 300-500rpm NPSHr: 3-8m Eff.: 79% Power: Max. 560kw Handling solids: 90mm Materials: R08, R26, R55, S02, S12, S21, S31, S42 etc

14x12ST-AHR Rubber Lined Slurry Pump is horizontal centrifugal heavy duty slurry pump and it is designed for the continuous pumping of high abrasive, high density slurries with minimal maintenance requirements. 14x12 pump will maintain high efficiency over the wear life of its components. The rubber and metal lined pumps feature casings which are radially split into two halves. Minimum casing bolts reduce maintenance and minimise downtime. The rubber lined slurry pump can be installed as multi-stage series.

Design Features:

√ Replaceable wear-resistant metal liners, impellers & volute liners are made of wear-resistant metal(such as A05, A49,and other high chrome alloy or synthetic rubber).

√ Bearing assembly uses cylindrical structure, adjusting the space between impeller & front liner easily, being removed completely when being repaired. Grease lubrication.

√ The impeller can be 2--6 blades ones, making the pump more effective. And the pump can achieve in excess of 87% in the best efficiency area.

√ Shaft seal could use the packing seal, expeller seal and mechanical seal. One pump also can be use packing seal with expeller seal together.

√ The discharge outlet can be positioned at intervals of 45 degrees by request and oriented to any 8 positions to suit installations and applications.
