Hospital Operating Theatre Using Medical Equipemt LED Operating Theater Shadowless Lights

Hospital Operating Theatre using Medical Equipemt LED Operating Theater Shadowless Lights

With innovations such as powerful LED technology, multi-lens matrixes, and adaptive lighting management, our Operating Theater Shadowless Lights System, gives users better shadowless lighting for medical staff operating.

Features & Specifications:

1, OSRAM brand, made in Germany LED units;

2, MITSUBISHI brand, made in Japan, PMMA materials optical grade lens for each LED unit;

3, With PWM sonstant-current controlling technology, avoid unsteady current impacting LED units, lamps service life can be 50,000 hours;

4, Each separated LED unit fixed with one separated heat radiating units, have excellent heat dissipation;

5, 6 LED units are series connected as one group, different groups are parallel connected as one lamp panel; If any group / unit fault, others work regular;

6, Every LED unit / Radiating unit can be dismantled without effecting others;

7, Engery saving, with maximum illumination as 160,000Lux, power dissipation is no more than 45W (One Lamp Panel);

8, Gives minium heat radiation to lighting area, when servicing, temperature rising around user's head area is no more than 2°C;

9, Color Rendering Index (CRI) no less than 96%;

10, Color Temperature 3 or 4 stages adjustable;

11, Lighting spot size stages adjustable; Or continuing adjustable (Optional function);

12, Illumination stages adjustable and continuing adjustable;

13, Turn-Off operating protection function, avoid misoperation;

14, One button to change over shadow-less lighting for surgery operating and cool white embient lighting for endoscopy operating (Optional function);

15, Streamline structure lamp satellites, to reduce effect for air flow, meets clean room air flow requirements;

16, Knock-Down handles, easy for sterilizing;

Lamp Satelltes Size: Φ700mm+Φ700mm

Single Lamp Panel LED Units Qty.: 84

Made in  Germany ceiling system and spring arms

Main Parameters (Single Satellite Lamp):

Optional Parts & Functions:

Camera in one lamp panel central handle;

Camera with separated arm;

4.3'' FHD Touch Screen control panel (display of camera);

Professional monitor with separated arm;

More than 10 different configurations models for users choosing.
