Tobee™ WARAMN Equivalent Vertical Sump Slurry Pump Manufacturer

Tobee™ TP(R) Vertical Slurry Pump are centrifugal slurry pumps submerged in sump to work.They are designed for delivering abrasive,large particle and high density slurries.These pumps have no need of any shaft seal and sealing water. They can also be operated normally for insufficient suction duties.Wet parts of type TP pump are made of abrasion-resistant metal. All parts of type TPR pump immersed in liquid are lined with rubber outer liner.They are suited to transport non-edge angle abrasive slurry.

Specification:

Specification:

Size (discharge): 40mm to 300mm
Capacity: 7.2~ 1492 m3/hr
Head: 5.5m ~ 47 m
Handing solids: 0 ~ 65mm
Concentration: 0%~ 70%
Material:High chrome alloy,Rubber,Stainless steel etc.

Detailed specification:

1.Cantilevered shaft design.

2.Double suction semi-open impeller.

3.Agitator option keeps solids in suspension.

4.TPR models feature full rubber covering for corrosion resistance.

5.Recessed impeller option passes oversized material.

6.Fully elastomer lined or hard metal fitted. No submerged bearings or packing. High capacity double suction design. Optional recessed impeller and suction agitator available.

7.No submerged bearings or packing. High capacity double suction design. Optional recessed impeller and suction agitator available.

Tobee™ TP(R) Vertical Slurry Pump Performance Parameter:

Tobee™ TP(R) Vertical Slurry Pump Component Diagram:

Tobee™ TP(R) Vertical Slurry Pump Structural Drawing:

Tobee™ TP(R) Vertical Slurry Pump Drive Type:

Tobee™ TP(R) Vertical Slurry Pump Quality  Control:

Tobee™ TP(R) Vertical Slurry Pump After-sales Service:

As the slurry pump wet ends parts such as the impeller,volute liner,FPL insert,Throat bush are consumption parts and we could provide you always the qualified slurry pump parts within very short time.

Packing Transport Services

Considering the order pump size and we could provide case or pallet as per your need to make sure it safe enough during the long distance road and ocean shipping.have its own export company  and so we could help you find the best ocean shipping solution and service for you from the goods out of factory to your destination.

Installation Services

Tobee Pump have more than 30 years experienced pump installation workers and are very aware of any onside application.We could provide abroad pump installation service and expect pump manufacturing and sales,abroad pump installation is getting more and more popular by our regular clients abroad.

Technical Support Services

Technical data sheet,Performance curve,General arrangement drawing,Operating manual will be sent within 24th for your checking, So Pls feel free to contact us If you have any need.

Tobee™ Slurry Pump On-Site Application:

1)Mine:Black, non-ferrous ore slurry material pump and all kinds of concentrate and tailings conveying.

2)Metallurgy:Transport various slurry for aluminium or steel manufacture.

3)Coal: Coal mining, washing and various coarse and fine coal slurry transportation.

4)Electricity:Remove power plant ash,wash ash,various ash dregs or ash slurry transportation.

5)Construction materials:Various mud sand slurry(such as Cement slurry) transportation.

6)Chemical: Phosphatic fertilizer or potassic fertilizer factory various abrasive slurry trasportation.

7)Water conservancy:Lake,river dredge, sediment,grit, High plastic clay Suction line to transportation.

Tobee™ TP(R) Vertical Slurry Pump Spare parts:

FAQ:
