Home > Products > Thin section ball bearings > KC090XP0 china thin section bearings manufacturers 228.6x247.65X9.525mm Packaging equipment bearing
KC090XP0 china thin section bearings manufacturers 228.6x247.65X9.525mm Packaging equipment bearing
- 1000 Piece / Pieces per Month
- T/T
- 7 days
- KC140XP0 Kaydon thin section ball bearings 355.6x374.65X9.525mm Packaging equipment bearing
- KC180XP0 Thin-section Bearing S-upplier Stock 457.2x476.25X9.525mm china thin section bearings manufacturers
- KC160XP0 Thin-section Bearings Supplier 406.4x425.45X9.525mm Packaging equipment bearing
- KC090XP0 china thin section bearings manufacturers 228.6x247.65X9.525mm Packaging equipment bearing
- KB200XP0 Kaydon standard508x523.875X7.938mm china thin section bearings manufacturers
- KB160XP0 Kaydon standard 406.4x422.275X7.938mm china thin section bearings manufacturers
Product Details
Brand Name: | ZLYQX | Place of Origin: | China | Model Number: | KC090XP0 |
Precision Rating: | P5 / P4 / P2 | Outside Diameter: | 247.65, | Bore Size: | 228.6, |
Product Description
Material: | GCR15 | Precision: | P5 / P4 / P2 |
---|---|---|---|
Structure: | Custom Made Available | OEM: | Available |
Dimennsion: | 228.6x247.65X9.525mm |
Description
ZLYQX is professional on the bearings inlcude Kaydon standard think section bearings ,THK IKO standard crossed roller bearings,INA standard Rotary Table bearings ,and also with many stock ones flexible deep groove ball bearings used for harmonic drive, custom made bearings avaible.
Kaydon thin-section bearings Structure
Open type deep groove ball bearing
Open type angular contact bearing
Open type four point contact bearing
Sealed type deep groove ball bearing
Sealed four point contact ball bearing
Feature
1. compact structure, light weight, low vibration and friction
2. high precision,
3. space and cost saving
4. best quality, long life
Main parameters
Dimension | Basic load rating | Weight | Interchange | |||||||
(inch/mm) | Basic Cap.N | Kg | ||||||||
d | D | L1 | L2 | Radial | Thrust | NTN | KAYDON | |||
Cor | Cr | Coa | Ca | |||||||
4 | 4.625 | 4.432 | 4.393 | 9340 | 3910 | 23380 | 9820 | 0.204 | KXC040 | KC040XP0 |
101.6 | 117.475 | 107.5 | 111.6 | |||||||
4.2 | 4.875 | 4.481 | 4.643 | 9870 | 4090 | 24710 | 10180 | 0.213 | KXC042 | KC042XP0 |
107.95 | 123.825 | 113.8 | 117.9 | |||||||
4.5 | 5.125 | 4.731 | 4.893 | 10400 | 4220 | 26050 | 10580 | 0.225 | KXC045 | KC045XP0 |
114.3 | 130.175 | 120.2 | 124.3 | |||||||
4.75 | 5.375 | 4.981 | 5.143 | 10940 | 4360 | 27380 | 10940 | 0.235 | KXC047 | KC047XP0 |
120.65 | 136.525 | 126.6 | 130.6 | |||||||
5 | 5.625 | 5.231 | 5.393 | 11510 | 4490 | 28720 | 11290 | 0.263 | KXC050 | KC050XP0 |
127 | 142.875 | 132.9 | 137 | |||||||
5.5 | 6.125 | 5.731 | 5.893 | 12580 | 4800 | 31380 | 11960 | 0.268 | KXC055 | KC055XP0 |
139.7 | 155.575 | 145.6 | 149.7 | |||||||
6 | 6.625 | 6.231 | 6.393 | 13650 | 5070 | 34050 | 12620 | 0.295 | KXC060 | KC060XP0 |
152.4 | 168.275 | 158.3 | 162.4 | |||||||
6.5 | 7.125 | 6.731 | 6.893 | 14710 | 5330 | 36760 | 13290 | 0.312 | KXC065 | KC065XP0 |
165.1 | 180.975 | 171 | 175.1 | |||||||
7 | 7.625 | 7.231 | 7.393 | 15780 | 5560 | 39430 | 13910 | 0.34 | KXC070 | KC070XP0 |
177.8 | 193.675 | 183.7 | 187.8 | |||||||
7.5 | 8.125 | 7.731 | 7.893 | 16850 | 5820 | 42090 | 14540 | 0.36 | KXC075 | KC075XP0 |
190.5 | 206.375 | 196.4 | 200.5 | |||||||
8 | 8.625 | 8.231 | 8.393 | 17910 | 6050 | 44760 | 15160 | 0.387 | KXC080 | KC080XP0 |
203.2 | 219.075 | 209.1 | 213.2 | |||||||
9 | 9.625 | 9.231 | 9.393 | 20050 | 6530 | 50100 | 16310 | 0.45 | KXC090 | KC090XP0 |
228.6 | 244.475 | 234.5 | 238.6 | |||||||
10 | 10.625 | 10.231 | 10.393 | 22180 | 6980 | 55430 | 17470 | 0.481 | KXC100 | KC100XP0 |
254 | 269.875 | 259.9 | 264 | |||||||
11 | 11.625 | 11.231 | 11.393 | 24310 | 7420 | 60810 | 18580 | 0.526 | KXC110 | KC110XP0 |
279.4 | 295.275 | 285.3 | 289.4 | |||||||
12 | 12.625 | 12.231 | 12.393 | 26450 | 7870 | 66140 | 19650 | 0.567 | KXC120 | KC120XP0 |
304.8 | 320.675 | 310.7 | 314.8 | |||||||
14 | 14.625 | 14.231 | 14.393 | 30720 | 8670 | 76810 | 21740 | 0.689 | KXC140 | KC140XP0 |
355.6 | 371.475 | 361.5 | 365.6 | |||||||
16 | 16.625 | 16.231 | 16.393 | 35030 | 9470 | 87520 | 23690 | 0.785 | KXC160 | KC160XP0 |
406.4 | 422.275 | 412.3 | 416.4 | |||||||
18 | 18.625 | 18.231 | 18.393 | 39290 | 10220 | 98190 | 25600 | 0.88 | KXC180 | KC180XP0 |
457.2 | 473.075 | 463.1 | 467.2 | |||||||
20 | 20.625 | 20.231 | 20.393 | 43560 | 10980 | 108900 | 27430 | 0.98 | KXC200 | KC200XP0 |
508 | 523.875 | 513.9 | 518 |
Application:
Aerospace and defense
Astronomy instrumentation
Fixturing and workholding equipment
Food processing equipment
Glassworking equipment
Index and rotary tables
Packaging equipment
Machine tools
Medical systems and medical devices
Optical scanning equipment
Models list
Open type thin section kaydon deep groove ball bearing:
KA020CP0, KA025CP0, KA030CP0, KA035CP0, KA040CP0, KA042CP0, KA045CP0, KA047CP0, KA050CP0, KA055CP0, KA060CP0, KA065CP0, KA070CP0, KA075CP0, KA080CP0, KA090CP0, KA100CP0, KA110CP0, KA120CP0,
KB020CP0, KB025CP0, KB030CP0, KB035CP0, KB040CP0, KB042CP0, KB045CP0, KB047CP0, KB050CP0, KB055CP0, KB060CP0, KB065CP0, KB070CP0, KB075CP0, KB080CP0, KB090CP0, KB100CP0, KB110CP0, KB120CP0, KB140CP0, KB160CP0, KB180CP0, KB200CP0,
KC040CP0, KC042CP0, KC045CP0, KC047CP0, KC050CP0, KC055CP0, KC060CP0, KC065CP0, KC070CP0, KC075CP0, KC080CP0, KC090CP0, KC100CP0, KC110CP0, KC120CP0, KC140CP0, KC160CP0, KC180CP0, KC200CP0,
KD040CP0, KD042CP0, KD045CP0, KD047CP0, KD050CP0, KD055CP0, KD060CP0, KD065CP0, KD070CP0, KD075CP0, KD080CP0, KD090CP0, KD100CP0, KD110CP0, KD120CP0, KD140CP0, KD160CP0, KD180CP0, KD200CP0,
KF040CP0, KF042CP0, KF045CP0, KF047CP0, KF050CP0, KF055CP0, KF060CP0, KF065CP0, KF070CP0, KF075CP0, KF080CP0, KF090CP0, KF100CP0, KF110CP0, KF120CP0, KF140CP0, KF160CP0, KF180CP0, KF200CP0,
KG040CP0, KG042CP0, KG045CP0, KG047CP0, KG050CP0, KG055CP0, KG060CP0, KG065CP0, KG070CP0, KG075CP0, KG080CP0, KG090CP0, KG100CP0, KG110CP0, KG120CP0, KG140CP0, KG160CP0, KG180CP0, KG200CP0,
Sealed type thin section kaydon deep groove ball bearing:
JA020CP0, JA025CP0, JA030CP0, JA035CP0, JA040CP0, JA042CP0, JA045CP0, JA047CP0, JA050CP0, JA055CP0, JA060CP0, JA065CP0,
JB020CP0, JB025CP0, JB030CP0, JB035CP0, JB040CP0, JB042CP0, JB045CP0, JB047CP0, JB050CP0, JB055CP0, JB060CP0, JB065CP0,
JU040CP0, JU042CP0, JU045CP0, JU047CP0, JU050CP0, JU055CP0, JU060CP0, JU065CP0, JU070CP0, JU075CP0, JU080CP0, JU090CP0, JU100CP0, JU110CP0, JU120CP0,
JG120CP0, JG140CP0, JG160CP0, JG180CP0, JG200CP0,
