Factory Machine Horizontal Furnace Price Making Automatic Tempered Glass

FOB Price

USD $235,000 - $385,000 / Set

1 Set(Min.Order)

Supply Ability 15 Set / Sets per Month
Port Qingdao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:	Lever	Place of Origin:	Henan, China	Certification:	CE
Warranty:	1 YEAR	Weight:	40000KGS
Dimension(LWH):	20403 * 5700 * 3500mm	Production Capacity:	98%	Condition:	New
Voltage:	380V	Machine Type:	Glass Tempering Furnace

Product Description

Name	Flat Tempered Glass	Curved Tempered Glass
Max Loading Area	2000 x 30000 mm	2000 x 1200mm
Min. Glass Size	150 x 300 mm	300 x 400mm
Glass Thickness	4~19mm	4~19mm
Min. Radius	150 x 300 mm	R≥65mm, for 4-8mm;
Productivity	15-17 loads per hour (take 5mm for example)	27 loads per hour (take 5mm float glass for sample)
Blower Quantity & Power	250KW x 1SET (Controlled by frequency inverter)
Finished product rate	≥97% (5mm as sample)

Main Features

1). The process for glass curvature forming is controlled by computer. You can input the needed radius data to computer, then required glass will be produced accordingly. But some time, for the new radius, you should make some mini-adjustment manually at the first time. This section is suitable to process 3.2mm automotive car side door glasses.

2). Materials: aluminum-alloy wheel with fiber rope

3). As separated structure, the cooling quench for bent tempering are fixed among the rollers and made actions for deformation accordingly. The cooling air is blown in from the grid back through heat resistant soft hose.
4). Without any mold. The forming method is automatic quench transmutation.
5). Fixed length swinging and reciprocating swinging during the whole process
6). There is sensor for glass length measuring.
7). It is very easy to change the glass with different thickness or radius.
