The main technical indexes
1.characteristic of voltage regulation
ratio of steady state voltage regulation ≤±2.5% ratio of transient state voltage regulation ≤±20-15%
steady time ≤1.5 ratio of voltage fluctuation ≤±1% voltage setting range of non-load 95-105%rated current
2.performance of governoring
ratio of steady governoring ≤5% ratio of transient governoring ≤±10%
steady time ≤5S ratio of rotating speed fluctuation ≤±0.5%
3.The generator set can overload 10% of the rated power for an hour after 12hours of rated power continuously
Gensets Model | BMMPPMGY50 | BMMPPMGY64 | BMMPPMGY75 | BMMPPMGY75 | BMMPPMGY90 | |
Rated Capacity(KVA) | 50/62.5 | 64/80 | 75/93.8 | 75/93.8 | 90/113 | |
| Engine | Diesel Model | YC6108CA | YC6108ZC | YC6108ZC | YC6108LCA | YC6108LCB |
| Rated power/Speed(KW/r/min) | 63/1500 | 80/1500 | 80/1500 | 90/1500 | 112/1500 | |
| Type | Vertical,inline,water-cooled,4 stroke | |||||
| Intake way | Natural aspiration | Turbo-cooled | Turbo-cooled | |||
| No. of Cylinder - bore*stroke | 6 - 108*125 | 6 - 108*132 | ||||
Starting type | Electric start | |||||
Total displacement(L) | 6.871 | 7.252 | ||||
| Min.fuel consumption g/(KW.h) | ≤198 | ≤197 | ≤195 | |||
| Oil capacity(L) | 16 | 22 | ||||
Lw Noise limit | ≤98 | |||||
| Generator | Lan Generator Model | TZHW-50 | TZHW-64 | TZHW-75 | TZHW-75 | TZHW-90 |
| Rated voltage | 400 | 400 | 400 | 400 | 400 | |
| Current(A) | 90.2 | 115 | 135 | 135 | 162 | |
| Regulator approach | AVR | |||||
| Freq.(Hz) | 50 | 50 | 50 | 50 | 50 | |
| Power factor(CosΦ) | 0.8 lagging | |||||
Phase | 3-phase | |||||
| Package | Net Weight(kg) | 1580 | 1500 | 1530 | 1560 | 1630 |
| Packing size L*W*H(mm) | 1900*800*1100 | 1960*800*1100 | 1980*800*1200 | 2000*820*1300 | ||
plywood carton, wooden cases or as your request
We can supply all scopes of marine engine,from 10kw-3000kw.If you need engines,don't miss us.Please feel free to contact us.We can provide you best service and prices!
