Indoor Fixed Installation LED Screen with Standard Cabinet

Item

Model

Parameter

    LED Module Info.

Pixel Pitch

P2.976 Indoor Rental

LED Lamp

SMD2020/SMD2121

IC Driver

MBI5124/ICN2153

LED Module Size

250*250mm

LED Module Resolution

84*84dots

Color Temperature

3000-9000K

Drive Mode

1/28 scan

   LED Cabinet Info.

Cabinet Size

500*500*mm or500mm x 1000mm

Cabinet Resolution

168*168dots

Cabinet Material

Die-casting Aluminum Cabinet

LED Module Quantities

2*2=4pcs /2*4=8pcs

Cabinet Net Weight

6.1kg/pc / 9.8kg/pc

   LED Display Info.

Best Viewing Distance

2.976m-100m

Viewing Angle

H: 140°/ V:140°

Pixel Density

160000dots/㎡

Brightness

800-1000nits/sqm

Max.Power Consumption

800W/㎡

Ave.Power Consumption

300W/㎡

Refresh Rate

1920Hz-3840H, can be adjusted

     Control System Info.

Operating System

WIN98/2000/NT/XP

Control Method

Synchronous display with control PC by DVI or Asynchronous with Wifi/4G/USB

Control System

Linsn, Nova-star, Colorlight or as you required

Display Content

Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.

Frame Frequency

50Hz or 60Hz

Transmission Distance

Multi mode fiber<500m, single mode fiber <30km,internet cable<100m

   Operation Info.

Working Temperature

-40℃--+60℃

Storage Temperature

-30℃--+80℃

Input Voltage

AC110V/AC220V

Humidity Environment

10%-95%

Lifespan

100,000hours

MTBF

10,000hours

Certificate

CE, CCC,FCC,ROHS,ISO9001
