2.5-150μm Herbs Powder Ultrafine Grinding Vibration Mill Milling Machine
- 1000 Set / Sets per Month
- qingdao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 30 days
-
China Sodium Bicarbonate Powder Grinding Vertical Air Classifier Mill Pulverizer
-
1.5-150 Micron Powder Grinding Pulverizer Fluidized Bed Spiral Jet Mill Micronization
-
Ultrafine Grinding Technology Milling Particle Size Micronizer Jet Mill
-
0.5-16um Ultrafine Grinding Steam Jet Mill Milling System
-
1-16um Powder Milling Machine Steam Air Jet Mill Price
-
R&D Ultrafine Grinding and Classifying Laboratory Jet Mill Price
Product Details
Brand Name: | ALPA | Place of Origin: | China | Model Number: | MZ |
Type: | Pulverizer | Certification: | CE,ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Warranty: | 1-year warranty | Weight: | Customizable | Dimension(L*W*H): | Customizable |
Condition: | New | Product Type: | Other, Powder | Voltage: | Local Voltage |
Power(W): | 0.37kw |
Product Description
2.5-150μm Herbs Powder Ultrafine Grinding Vibration Mill Milling Machine
Vibration Mill Features
Suitable for the grinding of toughness, fiber, sponge, high oil and high sugar content of materials which are difficult to be grinded by general grinders. Also for hardness and brittle materials. Widely used in Chinese herbal medicine, medicine, food, health products, cosmetics and other industries.
1.Available D50:2.5~150μm;
2.Suitable for plant pollen spores to break the wall, breaking the wall rate of 95%;
3.Designed for use in the pharmaceutical industry in accordance with GMP/FDA standards;
4.Grinding is carried out under fully sealed conditions, free of dust, high collecting efficiency, no environmental pollution;
5.PLC control system, easy operation;
6.Grinding chamber with cooling jacket, Adjust the temperature and flow of water to control the temperature of the grinding chamber; or configure a strong cooling system, operating at temperature of -30ºC~0º.
Vibration Mill Working Principle
By strong vibration of the vibration source, the material in the grinding chamber is in the fluidized state, and is subjected to the high-strength impact of the grinding rod, such as collision, cutting, grinding and squeezing, so that the material can reach the micron pulverization or cell wall disruption in a short time.
At same time, the grinder can also be used as a precision mixer and a coating modifier.
By adjusting the intensity of vibration, it is convenient to control the fineness of the material to be grinded. Dry and wet pulverizing operations are both available.
Meet GMP requirements, easy to assemble and disassemble, suitable for refueling operations.
It has various working configurations such as normal temperature, water cooling, low temperature, ultra-low temperature, anti-oxidation and anti-explosion, which can reduce the temperature in the grinding chamber and facilitate the crushing of heat-sensitive materials.
Widely used in Chinese herbal medicine, medicine, food, health products, cosmetics and other industries. It is a grinder with simple process and high cost performance.
Vibration Mill Parameters
Parameter | MZ03 | MZ06 | MZ10 | MZ30 | MZ50 | MZ100 | MZ200 |
Chamber Volume | 3L | 6L | 10L | 30L | 50L | 100L | 200L |
Grinding Volume | 0.6L | 1.2L | 2L | 5L | 10L | 20L | 40L |
Voltage | 220V | Three-phase 380V | Three-phase 380V | Three-phase 380V | Three-phase 380V | Three-phase 380V | Three-phase 380V |
Power | 0.37kw | 1.1kw | 0.75kw | 1.5kw | 2.2kw | 3.7kw | 7.5kw |
Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials. The above is only for selection reference.
(abbreviation: ALPA / Equity Code: 171033)
In the fields of ultrafine grinding and classification in the pharmaceutical, food, chemical, mineral, new materials, solid waste treatment and other industries, ALPA has mature and fully customized solutions and helps you design the ideal system to meet your needs.
Q: What service do you supply?
2). We supply sample processing tests in our test station where are equipped with our various machine products, to help clients compare performances of different types of machines or process.
3). We supply project engineering, automation engineering and civil engineering.
4). We send engineers to the clients’ project site and offer on-site technical instruction and supervision during the machine installation, commissioning and test run.
Q:How can I trust on your quality?
A: 1). All of the machine be tested successfully in Weifang workshop before shipment.
2). We supply one year warranty for all equipment and lifelong after-sales service.
3). We can test your material in our equipment before place the order, to ensure our equipment is suitable for your project.
4). Our engineers will go to your factory to install and debug the equipment, they will not be back until these equipment can produce qualified products.
Q:Does your company provide Engineers Abroad Service?
A: Sure, we provide it. And we can provide free training for on-site workers.
Q:How to train our staff about operation and maintenance?
A: We will provide detailed technical instructive pictures to teach them for the operation and maintenance. In addition, our engineers for guide assembly will teach your staff on site.
