Common rail injector test bench CRI-NT816C for testing common rail injector + piezo injector
- 100 Set / Sets per Month
- Shanghai Qingdao Ningbo Xiamen Shenzhen
- T/T Credit Card
You May Like
-
NANT Diesel Fuel Common Rail Injector Test Bench CRI-NT816E
-
common rail injector test bench NT816F with Bo-sch 3rd stage repair solution
-
CR815 comprehensive common rail injector test bench test equipment
-
Common Rail Injector Test Bench CRI-NT207
-
China Factory Common Rail injector and Pump Test Bench NT815
-
China Factory Cheap Used CRDI Portable CRI-NT207 common rail Injector piezo injector test bench Bosch/Denso/Cummins ISG/Delphi
Product Details
| Brand Name | NANT | Place of Origin | Henan, China | |
| Model Number | 816C | Type | Engine Analyzer | |
| Certification | ISO CE | Voltage | 3 phases 380V 60HZ/220V 60HZ,2 phases 220V 60HZ | |
| Power | 4KW | Warranty | 1 Years | |
| Applicable Models | common rail injector, electric piezo injector |
Product Description
Common rail injector test bench CRI-NT816C for testing common rail injector + piezo injector
Functions:
1.Application: Bosch,Delphi,Denso,Siemens solenoid valve common rail injector.
2.High pressure cleaning to remove the impurities.
3.Measure the injected & return fuel quantity under full-loaded, idling, pre-injection and emission status.
4.Sealing performance test :check whether nozzle, nozzle cap and solenoid valve leaks oil
5.Check whether the injector orifice is obstructed through atomization test.
6.User can add and edit the data by themselves.
7.Save and print the testing results & customer information.
Characteristics:
1.Computer control, 19” LCD operation.
2.Germany flow sensor
3.Bosch common rail system is used.
4.Rail pressure is controlled accurately by DRV.
5.Original Bosch CP1 pump and common rail system are equipped.
6.Industrial temperature controlling kit to keep fuel temperature constant at 40±2℃
7.Frequency converter is used to change the rotation speed
8.Iron fuel tank with industrial air-conditioner inside .
9.Frequency converter is used to change the rotation speed.
10.High test precision, simple operation, low noise, and saving energy.
Main technical parameters:
1. Rated output power: 4KW
2. Test rang of rail pressure: 0-1800bar
3.Oil pump rotation speed: 0-3500rpm
4.Test precision of rail pressure: ±2Mpa
5.Test temperature of test oil:40±2℃
6. Filter precision of test oil: less than 5μ
7. Capacity of tank: 28L
8. Dimension: 1200X900X1650MM
9. Aggregate weight: 350KG
10. Electricity: 380V, 50Hz, 3 phase
220V,60Hz, 3 phase
System advantage:
1.Basic type common rail injector test bench 816E Embedded industrial computer system: high speed operation and stable performance.
2.Original Bosch test bench database.Test accuracy similar with the world-leading test bench.
3.The database can be edited, saved, modified and delete
4.Include Chinese,English,German,Spanish,French,Russian and Portuguese operating interface,which is proper for global using all around the world.
5.Support customized products and application.
Nanyang NanTai Experimental Equipment Co.,Ltd is a joint-stock enterprise that produces common rail test bench, traditional diesel fuel injection pump test bench, Nozzle Tester, and sells spares parts for repairing variety of electronic diesel injection systems to serve the automobile aftermarket all over the world.
The company pursues high standard manufacturing and qualified products. All the products have passed the quality system certification of ISO9001:2008 & CE certificate and entered European market. Depending on the stable and lasting capabilities, our products are well known to international market such as Russia, Mongolia, Bulgaria ,Albania, Argentina, South Africa, Germany, Romania, Ukraine, Haiti, Iraq, Britain, Brazil, Malaysia and etc
Q: Are you trading company or manufacturer ?
A: We are test bench assembling factory. We have had test bench for 20 years.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: How about the use of maintenance technology and equipment ?
A:We have free training about test bench,injector and pump maintenance.
Q: Why should I choose your product?
A: We can provide you the best quality and the most competitive price ,and we have our own engineer, if you have any requirements you can contact us directly.
