Factory Use Automatic Lifting System Snacks Fish and Chips Onion Fried Food Frying Machine

Name: Factory Use Automatic Lifting System Snacks Fish and Chips Onion Fried Food Frying Machine
Brand: Joyshine
Availability: InStock

FOB Price

USD $12,460 - $13,200 / Set

1 Set(Min.Order)

Supply Ability 20 Set / Sets per Month
Port Qingdao/Ningbo/Shanghai/Tianjin
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:

Joyshine

Place of Origin:

Henan, China

Product Description

Products Description

Factory Use Automatic Lifting System Snacks Fish and Chips Onion Fried Food Frying Machine

This automatic continuous fryer machine is widely used in restaurant and all food industrial, also an indispensable machine in kinds of snack processing line. It consists of automatic belt conveying system, automatic lifting system, oil adding system, oil filtering system and automatic temperature control system.

Features & Advantages:

1	Conveyor belt speed is adjustable for different frying time according to different products
2	Electricity, gas or diesel, and also electromagnetism as power source Gas or diesel model uses the most advanced and reliable Italy imported Riello brand burner with the advantage of fuel economy, low noise, prevent heating loss, high efficiency
3	Automatic lifting system for easy cleaning the machine and save human power
4	Oil circulation system to continuously filter oil residue and extend the service life of cooking
5	Oil level alarm and automatic oil temperature control (0-300°C)
6	Double belt design to prevent floating, ensure complete and perfect frying effect
7	Scrapers fixed on the belt to make the products come out easily
8	Fire-extinguishing system can be added according to your demand
9	PLC touch screen control panel

Detailed Description

PLC Control Panel

To control the whole machine working, adjust temperature and mesh belt speed

Double Mesh Belt

The upper mesh belt is in the shape of a wave and has a baffle plate to drive the transfer of light materials such as potato chips

to make it evenly fried to achieve better frying effect

Automatic Lifting Device

Lift the mesh belt for easy cleaning the machine inside and save human power

Filter Screen

Preliminary rough filtration of residue

Oil Storage Tank

For Oil storage after one day's working

Vacuum Oil Filtering Device

Continuously refined filter the oil while frying

Product Paramenters

Model	Dimension	Weight	Power (electric heating)
JS-LXYZ-2500	25008001300mm	500kg	24kw
JS-LXYZ-3000	300012002200mm	800kg	80kw
JS-LXYZ-4000	400012002200mm	1000kg	120kw
JS-LXYZ-5000	500012002200mm	1200kg	180kw
JS-LXYZ-6000	600012002200mm	1500kg	200kw

Contact us for more details please!

Application

This continuous fryer machine is suitable for various kinds of fried food like meat pie, chicken nuggets, potato chips, banana chips, spring rolls, peanuts and many other snacks.It is widely used in food industry with large capacity

This continuous frying machine always works together with other machines like deoiling machine to combine one whole production line.

Contact Us

Henan Joyshine Machinery Co., Ltd.

*Email
Please enter Your valid email address.
*To

Henan Joyshine Machinery Co., Ltd.
*Message
Your inquiry content must be between 20 to 5000 characters.
Please enter a correct verification code.

Product Categories

Poultry Cutter Machine	Vegetable washing machine	Vegetable cutting machine	Vegetable and fruit production line
Ungrouped	Seasoning machine	Roti maker	Poultry Slaughter Line
Poultry Scalder Machine	Poultry Plucker Machine	Air drying line	Packing machine
Other Poultry processing equipment	Meat processing Equipment	Fryer	Fruit grading machine
Food spinner	Chicken Feet Processing Line	Blanching machine

New Products

Application:	Kinds of snacks, fried food, puff food
Payment:	T/T, Alibaba Trade Assurance, Western Union, PayPal, Alipay, WechatPay, L/C
Lead Time:	7-15 working days after deposit
Voltage:	We normally make it 220v/50Hz/single phase or 380v/50Hz/3 phases. But it can be made according to your demand, like 110v/60Hz/single phase or 415v/50Hz/3 phases etc.
Packing:	For LCL, we use export standard fumigation wooden case For FCL, sometimes no packing
Shipping:	Shipping by express, air, railway and sea.
Warranty:	We promise 2 years guarantee for non-human damage fator
OEM:	Customization of nameplate, material, motor brand, packaging, etc.
Spare Parts:	If you want to change some spare parts after long time using, feel free to contact us, we keep whole life spare parts supply
