1kg 2kg Automatic flour powder milk powder packing machine in shanghai

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port NINGBO
Payment Terms:T/T L/C Other

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	China	Model Number:	SN-420F	After-sales Service Provided:	Engineers available to service machinery overseas
Dimension(LWH):	L1320 × W920 × H1390mm	Voltage:	220V	Power:	2.5KW
Function:	Filling	Application:	Beverage, Food, Medical	Condition:	New
Automatic Grade:	Automatic	Driven Type:	Electric	Packaging Material:	Glass, Plastic
Packaging Type:	Bottles

Product Description

Usage:This machine is widely used for packing powder products: such as milk powder, flour, starch, coffee powder, spices, curry powder, protein powder, condiment, essence，herbal powder, chemical and medical powder products to big packing bag. This machine can automatically complete material lifting(optional)--multi-head weighter /Cup measuring(optional)--coding(optional)--bag making--filling--gas injection / exhaust (optional)--sealing--counting-- conveying finished products(optional)--sorting finished products(optional).

Technical parameter:

Model	SN-420F （about 100-1200g）	SN-520F （about 300g-2200g）	SN-720F （about 500g-5500g）
Packing speed	5-70 bags/min	5-60 bags/min	5-55 bags/min
Packing volume	1000ml（can be customized）	2000ml（can be customized）	4000ml（can be customized）
Making bag size	L: 60-300mm, W: 80-200mm	L: 80-400mm, W: 150-250mm	L: 80-450mm, W: 200-350mm
Film width	≤ 420mm	≤ 520mm	≤ 720mm
Thickness of film roll	0.04-0.09mm	0.04-0.09mm	0.04-0.09mm
Pulling film type	Double belt pull film	Double belt pull film	Double belt pull film
Air consumption	0.8Mpa, 0.5m³/min	0.8Mpa, 0.4m³/min	0.8Mpa, 0.4m³/min
Packing accuracy	≤ ±1%	≤ ±1%	≤ ±1%
Power	2.5 KW	2.5 KW	3.0 KW
Power supply	AC220V, 50/60Hz	AC220V, 50/60Hz	AC220V, 50/60Hz
Seal type	Pillow seal, Gusset bag, Block bottom bag	Pillow seal, Gusset bag, Block bottom bag	Pillow seal, Gusset bag, Block bottom bag
Main machine net weight	450kg	550kg	700kg
Main machine dimension	L1320 × W920 × H2100mm	L1500 × W1140 × H2700mm	L1800 × W1250 × H3100mm

HOW TO ORDER

1.Send us your products picture,material,size and your requirements.

2.Confirm the machine model and sign the PI.

3.You arrange the 30% deposit,send your product samples to us test the machine.

4.You can arrange people to our factory to inspect the machine after we finish the produce,then arrange pay for balance money.

5.We send out the machine to you.If you need technicist to your site to debug and assemble the mahine,we can arrange.

Changsha Shangnuo machinery co. ltd pay attention to technical innovation, according to the actual production situation of customers, use new technology, new ideas to develop professional production equipment, improve your production efficiency! Pls feel free to contact with us wechat: 008613974614255
