hot dip galvanized electric wiring conduit pipe
- 3000 Metric Ton / Metric Tons per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Certification: | UL | Thickness: | 0.104, 0.266 |
Application: | Structure Pipe | Surface Treatment: | Galvanized | Technique: | ERW |
Alloy Or Not: | Non-alloy | Outer Diameter: | 0.84 - 6.625 inch | ||
Secondary Or Not: | Non-secondary | Special Pipe: | EMT Pipe | Section Shape: | Round |
Product Description
EastConduit RMC is manufactured from high-strength steel coil, and produced according to the standard of ANSI C80.1(UL6). The interior surface of our conduit is free from defect with a smooth welded seam. It is hot dipped galvanized inside and outside, so that metal-to-metal contact and galvanic protection against corrosion are provided,and the furface of the conduit is coated with a clear lacquer coating to inhibit white rust and increase corrosion resistance. And the conduit is threaded on both ends, with a coupling applied to one end and a by size color coded thread protector to the other as per table. The interior surface provides a smooth continuous raceway for easy wire pulling. Our conduits ductility characteristics provide for easy bending, cutting, and threading in the field.
Factory hot sale rigid nonferrous metallic conduit
Product details
Thickness | 1.3mm---1.8mm of Bs4568 class 4 gi cable pipe |
Application | Used for protecting cables and wires |
Standard | UL6 |
Technique | ERW |
Product Keywords | rigid nonferrous metallic conduit |
Product Information | |||||
Brand : | east conduit | ||||
Standard: | UL6 & ANSI C80.1; File No.:E308290; | ||||
Trade Size : | from 1/2" to 6"; | ||||
Both Ends: | threaded both ends with one coupling and plastic cap; | ||||
Length: | 3050mm or according to customer's requirement; | ||||
Usage: | through the electrical wires with the purpose of protection for the electrical raceway system; | ||||
Surface Finished: | Hot dip galvanized(HDG); | ||||
Material : | carbon steel coil; | ||||
Package: | the conduits coverd with pvc paper then tied with steel straps; | ||||
Delivery Time: | 20 to 30 days after we receive your advance payment or copy of L/C; | ||||
Payment Term: | L/C at sight or T/T; |
Dimension and Weight Chart
Trade Size | Nominal Wt. per 100Ft(30.5M) | Nominal Outside Diameter | Nominal Wall Thickness | ||||
U.S. | Metric | Lbs | Kg | In. | mm | In. | mm |
1/2" | 16 | 82 | 37.2 | 0.84 | 21.3 | 0.104 | 2.6 |
3/4" | 21 | 109 | 49.44 | 1.05 | 26.7 | 0.107 | 2.7 |
1" | 27 | 161 | 73.03 | 1.315 | 33.4 | 0.126 | 3.2 |
1-1/4" | 35 | 218 | 98.88 | 1.66 | 42.2 | 0.133 | 3.4 |
1-1/2" | 41 | 263 | 119.3 | 1.9 | 48.3 | 0.138 | 3.5 |
2" | 53 | 350 | 158.76 | 2.375 | 60.3 | 0.146 | 3.7 |
2-1/2" | 63 | 559 | 253.56 | 2.875 | 73 | 0.193 | 4.9 |
3" | 78 | 727 | 329.77 | 3.5 | 88.9 | 0.205 | 5.2 |
3-1/2" | 91 | 880 | 399.17 | 4 | 101.6 | 0.215 | 5.5 |
4" | 103 | 1030 | 467.21 | 4.5 | 114.3 | 0.225 | 5.7 |
5" | 129 | 1400 | 635.04 | 5.563 | 141.3 | 0.245 | 6.2 |
6" | 155 | 1840 | 834.62 | 6.625 | 168.3 | 0.266 | 6.8 |
Applicable tolerances:
Length: 10Ft (3.05m) ± ¼" (±6.35mm).
Outside Diameter: ½"-2" ±0.015" (±0.38mm); 2½"-4" ±0.025" (±0.64mm); 5"-6" ± 1%
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
35-40 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
