GW180 worm gear motor for making locking motors Thin brush motor

 Motor Model:GW180

6V:
No-load speed:4 rpm /min  Rated speed:3 rpm / min   Rated torque:5.4 kg.cm
No-load speed:6rpm / min  Rated speed 4.5 rpm / min  Rated torque:3.5kg.cm
No-load speed:9 rpm / min  Rated speed 6.8 rpm / min  Rated torque: 2.5kg.cm

No-load speed:12 rpm / min Rated speed 9 rpm / min   Rated torque :1.6kg.cm
No-load speed:25 rpm / min Rated speed 19 rpm / min  Rated torque :0.8kg.cm

12V:

No-load speed:8.5 rpm /min  Rated speed:6.5 rpm / min   Rated torque:7.5 kg.cm
No-load speed:13rpm / min  Rated speed 10rpm / min  Rated torque:5kg.cm
No-load speed:18rpm / min  Rated speed 14rpm / min  Rated torque: 3.4kg.cm

No-load speed:26rpm / min Rated speed 20 rpm / min   Rated torque :2.4kg.cm
No-load speed:52 rpm / min Rated speed40 rpm / min  Rated torque :1.2kg.cm

Rated current: 0.3A

Dear customer,pls tell us the voltage and speed you need,so that we can send you the right product.or we will send you randomly.

Paypal & Credit card & Bank Transfer (TT) & Western Union,all is ok for us,you can choose whichever you like.
Refunds & Return:
1>Thank you for your order with YXS Technology,we will provide our best service to you,your satisfaction is our motivation.
2>We offer 60 days warranty for all parts. Products will be tested before shipment to ensure they are in good condition.
3>Buyer must contact us before returning any parts. All returns must be made within 14 days from this shipment date. Return must be in new condition(the SAME CONDITION as it was sent to you).

1>Goods normally will be shipped out within 3 working days after the payment arrived
2>The buyer is responsible for all shipping cost and all bank charges.
Goods can be shipped by DHL/FedEx /TNT/UPS /EMS/Russia Special Line Express or other special method.
3>Remark:When parts arrived at buyer’s local custom, we do not responsible for any incurred custom duty or import tax .

YXS Technology Co., Ltd has been in this industy for more than 10 years,we have best quanlity and service for all our customers all around the world.Customers' satisfaction is our motivation to improve ourselves.Pls do feel free to contact us with any inquiry anytime if you have any doubts or needs,we will surely reply you asap.

Sincerely

Sofia
