DN40 stainless steel 304 high temperature high pressure metal braided hose DIN flange connection

Name: DN40 stainless steel 304 high temperature high pressure metal braided hose DIN flange connection
Brand: JIEYI
Availability: InStock

FOB Price

USD $3.5 - $15 / Piece

5 Pieces(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Qingdao
Payment Terms:T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Brand Name:	JIEYI	Place of Origin:	China	Model Number:	MF20-01 metal hose
Certification:	ISO	Thickness:	1 ~ 3 mm	Type:	Seamless
Application:	Steel industry, petrochemical industry, electric heating industry, transportation industry, medical and health industry	Standard:	ASTM, AISI, DIN, EN, GB, JIS	Outer Diameter:	DN20
Welding Line Type:	Spiral Welded	Steel Grade:	300 Series

Product Description

DN40 stainless steel 304 high temperature high pressure metal braided hose DIN flange connection

Metal hose products include oil and suction hoses, steam hoses, sandblasting hoses, acid and alkali suction hoses, food hoses, oxygen blowing hoses and various special-shaped hoses. It is widely used in machinery, chemical, petroleum, metallurgy, food and other industries.

Material
Inner Core: Corrugated Stainless Steel
•Flexible metal hose stainless steel core strengths are available in 304, 321 and 316L stainless steel
•Stainless steel tubing formed into corrugations parallel to one another
•Helical / Convoluted option available upon request

Outer Core:Braided Stainless Steel Layers
•Purchase corrugated core hose with no layers, single or double braided
•Flexible metal hose outer braid layers made from 304 stainless steel.

Use parameters
Pressure	60 bar / 6.0 MPa
Temperature	300 ℃ / 572 °F
Lenght	Customized
Media	Water, Steam, Hot oil
Size	1/4'' ~ 10''; customized
Connection	Flange
Standard	DIN, ANSI, JIS
Material	SS304
Product name	Metal hose

What is the features of our metal flexible hose?

1.Bend easily and easy to install.

2.It is able to bear corrosion resistance and heat resistance strongly, stainless steel materials can be used safely for years .

3.Outside is covered with stainless steel wire braided ,have high bearing capacity.

4. Applied to repeated motion region in high-temperature areas, good anti-fatigue performance.

5.Diameter and length,welded on the end of hose can be produced as customer's requirement.a variety of end fitting configurations such as threaded(both NPT and BSP);fixed and floating flanges(stainless steel and carbon steel);welding neck connection and quick fittings.

To properly design a metal hose assembly for a particular application, the following design parameters must be determinde:

1. Temperature-----You should provide us information as the temperature to which the assembly is exposed a

proper fit.

2. Size-----The diameter of the connections in which the assembly will be installed is needed to provide.

3. Media-----This is improtant since you must be sure that the assembly's components are chemically

compatible with the media going through the hose as well as the environment in which the hose is installed.

4. Pressure-----identify the internal pressure to which the assembly will be exposed. This information is

important to determine if the assembly is strong enough for the application.

5. Indenify the necessary end fittings-----This is required since fittings for the assembly must be chosen to

properly fit the mating connection.

Product Show

Company Profile

Certificate

Delivery

Product packaging

Warehouse corner

Why choose us

1.Always Innovating
We have accumulated rich experirence in producing Rotary Joint,advanced equipment,advanced technology,professional staff.we keep on Innovating all the time.

2.Design Concept
Reasonable design, advanced structure,superior quality,long service life.

3.Reliable Quality
We are Alibaba Assessed Supplier,our products are certified by ISO9001,CE etc.

4.Short leading time
We have professional and advanced machines.we have 4 production line,can produce production quickly.

5.Good Price
We are crontroling each part cost so we can give customers the competitive price.

6.Internal Control
Internal inspection,all our products must be checked 3 times before packing.

7.Prompt Reply
We’ll reply your enquiry within 2 hours.

Contact us

If you have any needs, please feel free to contact us. We can produce according to your samples or drawings, we can also customize the design drawings for you according to your requirements, and then send them to you for confirmation!
