Automatic three 3 and four 4 axis liquid solder dispensing robot

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

400D

Item/Model	LJ-D4411	LJ-D4412	LJ-D4413	LJ-D4414
Number of axes	3	3	3	3
Maximum working area (X / Y / Z)	400 / 400 / 100 mm	400 / 400 / 100 mm	400 / 400 / 100 mm	400 /400 / 100 mm
Head Number	1	2	3	4
Rotation Axis	-	-	-	-
Workpiece payload	10 kg (22.0 lb)	10 kg (22.0 lb)	10 kg (22.0 lb)	10 kg (22.0 lb)
Tool payload	5 kg (11.0 lb)	5 kg (11.0 lb)	5 kg (11.0 lb)	5 kg (11.0 lb)
Maximum speed(XY / Z)	500 / 320 mm/sec	500 / 320 mm/sec	500 / 320 mm/sec	500 / 320 mm/sec
Unit weight	50 kg	50 kg	52kg	53 kg
Dimensions	560W x 690H x650D mm	560W x 690H x650D mm	560W x 690H x650D mm	560W x 690H x650D mm
Drive system	3-phase micro-stepping motor	3-phase micro-stepping motor	3-phase micro-stepping motor	3-phase micro-stepping motor
Memory capacity	1–99 programs	1–99 programs	1–99 programs	1–99 programs
	1–9,999 points per program	1–9,999 points per program	1–9,999 points per program	1–9,999 points per program
Data storage	USB	USB	USB	USB
General purpose I/O	8 inputs / 8 outputs	8 inputs / 8 outputs	8 inputs / 8 outputs	8 inputs / 8 outputs
Drive method	PTP and CP	PTP and CP	PTP and CP	PTP and CP
Dispensing controller	External	External	External	External
Power supply	Auto-switching	Auto-switching	Auto-switching	Auto-switching
	AC100–240V, 750 W	AC100–240V, 750 W	AC100–240V, 750 W	AC100–240V, 750 W
Interpolation	3 axes (3D space)	3 axes (3D space)	3 axes (3D space)	3 axes (3D space)
Repeatability	±0.02 mm	±0.02 mm	±0.02 mm	±0.02 mm
Working temperature	10–40° C (50–104° F)	10–40° C (50–104° F)	10–40° C (50–104° F)	10–40° C (50–104° F)
Teach pendant(ENG)	Included	Included	Included	Included
Moving Method	Point to Point, Linear, Circle	Point to Point, Linear, Circle	Point to Point, Linear, Circle	Point to Point, Linear, Circle
Available Graph	Line, Circle, Arc, Continuous Line, 3D Irregularity Line	Line, Circle, Arc, Continuous Line, 3D Irregularity Line	Line, Circle, Arc, Continuous Line, 3D Irregularity Line	Line, Circle, Arc, Continuous Line, 3D Irregularity Line
Heating function	Optional	Optional	Optional	Optional
Preheat function	Optional	Optional	Optional	Optional
Pressure	4-7kg f/cm2	4-7kg f/cm2	4-7kg f/cm2	4-7kg f/cm2
Approvals	CE	CE	CE	CE

start order

CHAT NOW

SEND INQUIRY

Packaging & Shipping

Professional packaging: 1pc with poly bag.
wooden case and canton box are available.
make sure the machine safe.
Shipping :7 working days after order confirmed

Company Information

Liujiang 10 years focused on research and development in the field of dispensing and Solder,Lock screw manufacture.

Dongguan Liujiang Automation Co., Ltd. It was founded in 2008, is a specialized in hot melt glue machine,pur hot melt glue machine. automatic dispensing machine, electronic product dispensing machines, 3/4/5 axis dispensing machine, PCB dispensing machines .Liujiang have granted the certification of CE. It’s a research,development,manufacturing and sales of international high and new technology enterprise. R& D Headoffice is located in Dongguan city, Guangdong province, China. The total area is 2000 square meters, We have advanced R&D center of the engineers and technicians 18 people, 2 modern production workshops , more than 130 staffs.

Our Services

1. Your inquiry related to our products or prices will be replied in 24hours.
2. Well-trained and experienced staffs to answer all your inquiries in fluent English
3. OEM&ODM
4. Good quality paper box & carton packing
5. Double check before shipping
6. Safely Shipping method,such as DHL /EMS /FEDEX/TNT /UPS
7. Ocean Freight or cargo forwarder service
8. Sample order in small quantity is acceptable
For more detailed information or catalog, please kindly contact us!
