358 Welded Mesh Security Fence Security Spike

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

QYM-High security fence

QYM- high security fencing is well known in the world as an anti-climb & anti cut through barrier, while providing the lowest level of visual impact to the surroundings. With its small mesh aperture, it is effectively finger proof and very difficult to attack by using conventional hand tools. The panels are welded with high quality carbon steel wires. Designed to give attractive, long lasting and secure perimeter protection for industrial and commercial properties,public utilities and is also good choice for electronic alarm and detection systems no blind spots for CCTV. Military, airports, secure units and prisons.

Mesh	Wire Thickness	Surface Treatment	Panel Width	Height
76.2x12.7mm	Horizontal wire:3.0 ,3.5,4.0mm Vertical wire :4.0mm	Galvanized and Electrostatic polyester powder coated or hot dipped galvanized	2.50m or 2.20m	1800mm
					2000mm
					2100mm
					2200mm
					2400mm
					2500mm
					3000mm

*Weld strength: - 75% of the minimum tensile strength of the wire, Tensile range 540-690 N/m2

Mesh	Wire Thickness	Surface Treatment	Folds NOS	Panel Width	Height
76.2x12.7mm	Horizontal wire: 3.0 ,3.5,4.0mm Vertical wire : 4.0mm	Galvanized and Electrostatic polyester powder coatedor hot dipped galvanized	3	2.50m or 2.20m	1800mm
						3	2000mm
						4	2100mm
						4	2200mm
						4	2400mm
						5	2500mm
						6	3000mm

*Weld strength: - 75% of the minimum tensile strength of the wire, Tensile range 540-690 N/m2

Mesh	Wire Thickness	Surface Treatment	Panel Width	Height
100x15mm	Horizontal wire:3.5mm Vertical wire :5.5mm	Galvanized and Electrostatic polyester powder coated or hot dipped galvanized	2.50m or 2.20m	1800mm
					2000mm
					2100mm
					2200mm
					2400mm
					2500mm
					3000mm

*With additional horizontal wire of 3.5mm at18cm intervals
*Weld strength: - 75% of the minimum tensile strength of the wire, Tensile range 540-690 N/m2

Profile A	Wall Thickness	Surface Treatment	Length	Rain hat
80x60mm	3.00mm	Galvanized and Electrostatic polyester powder coated or hot dipped galvanized	On the basis of panel height	Plastic or Metal

Profile B	Wall Thickness	Surface Treatment	Length	Rain hat
83x64mm	3.00mm	Galvanized and Electrostatic polyester powder coated or hot dipped galvanized	On the basis of panel height	Plastic or Metal

Company Information

Hebei Qianye Metal Product Co., Ltd is a company engaged in production and exportation of metal fence as well as other metal products, such as airport fence, barb wire, chain link fence, concertina razor wire, double wire fence, euro fence, palisade fence, temporary fence, welded mesh, welded mesh fence, wire mesh, etc. Its registered capital is RMB50, 100, 000(about USD 7,400, 000), covering a land area of 30, 000 square meters.
Service
1>Quality Products:
We follow the policy of Seeking Development through Quality and Establishing Reputation via
Quality Products. We try to meet customers' requirements with excellent quality products.
2>Honest Service:
We offer honest service to customers. We provide products with sincere and excellent service and the most prompt delivery.
3>Innovation:
We have advanced inspection and production equipment and can develop new products to meet the demand of market. We can also accept customized orders. Our strong R&D capability enables us to innovate almost everyday.

Packing & Shipping

1>Panel Packing:
It has soft sponge at the botom of the pallet to avoid the botom fence panel to be damaged by metal pallet.
It has 4 metal corners to keep the pallet be more strong.
It has metal plate under the plastic bandage to avoid the bandage to presure the fence panel.
It has wood plate on the top of pallet to keep the above pallet to de destroyed by the pallet.
2>Post Packing:
The post is covered with plasti cap then packed with plastic flim. Clips packed by set.
3>Accessories:
Plastic bags + carton boxes

FAQ

Q: What's QYM's after service policy?
A: QYM's after service staff will contact you when you received the products, and ask for your comments on the products. Anyissues on QYM's products, please send email or call us. QYM will service you timely with whole-heartedness and profession.

Q: What's the MOQ of QYM's product?
A: Different item has different MOQ. Normally 1X20FCL is preferred, LCL could be negotiable.

Q: How can we get the quotation from QYM?
A: Please send your inquiry to QYM's official email.

Q: How to be QYM's agent, wholeseller or distributor in my country?
A: Please send your company's basic information and application to my email adress. A feedback will be sent to you within 7 working days.
