PD194Z-E14D NB-IoT Band 3/5/8 comm remote power monitoring meter

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

Product name: PD194Z-E14D NB-IoT Band 3/5/8 comm remote power monitoring meter

This series of multi-function powermeters support all-parameter measurement, bi-directional energy metering, four-quadrant reactive metering and harmonic analysis.they can be connected to power monitoring system and energy management system to realize remote data monitoring.

Technical Specification

Accuracy		Voltage,current:0.2%;power:0.5%,frequency:±0.01HZ;Active energy:0.5s
Data update rate		1s
Signal Input	Rated current	External CT
		Rated voltage	AC 3x220V/380V
		Overload	Continuous:2In,instantaneous:10In/5s Continuous:1.2Un,instantaneous:2Un/1min
		Energy consumption	≤0.1VA
		Fequency	45~65HZ
Communication Port	NB-IoT	Band 3/5/8
Energy pulse		Optocoupler isolation ,pulse width 80ms±20%
Digital Input		Optocoupler isolation ,passive dry contact
Relay Output		Contact capacity AC250V 5A or DC 30V 5A
Auxiliary power supply	Working range	AC/DC 80~270V
Auxiliary power supply		Energy consumption	≤5VA
Environment condition	Working temperature	-10~55℃
		Storage temperature	-25~70℃
		Relative humidity	≤93%RH
		Altitude	≤2500m
Safety	Insulation	Signal power supply output terminal to case resistance ≥100MΩ
Safety		Withstand voltage	Power supply，input and output ≥2kv
Protection level		IP54

Optional CT

Recommend Products

Application

■Data Acquisition

■Energy Management

■Remote Power Monitoring

■Rail Mounting Instrument

■Energy Efficiency Management
