S3I48 panel mounted LED display 3 phase current digital ampere meter
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
S3U48 panel mounted 3 phase RS485 interface digital voltmeter
-
LNF26 LCD display RS485 communication 3 phase panel smart energy meter
-
S3U96 96x96mm panel mounted AC 3 phase digital voltage meter
-
Solar energy system multifunctional high accuracy DC volt/current energy meter
-
LNF56 smart panel mounted real-time measurement RTM energy meter
-
LNF66 RS485 communication embedded multifunction smart energy meter
Product Description
Product Description
Product Name:S3I48 panel mounted LED display 3 phase current digital ampere meter
The digital ammeter is suitable for single-phase or three-phase current parameter measurement in power distribution systems. This series of meters is programmable, supports digital input, relay output, analog output and communication functions（Mod-bus-RTU). It provides different mounting dimensions and can directly replace the analog pointer ammeter.
Technical parameters
Accuracy | 0.5%(default),0.2% | |
Data update rate | 1s | |
Input | Current | Rated value:AC 1A,5A |
Voltage | Rated value:AC 100V,220V,400V etc | |
Overload | Continuous:2 times of rated value | |
Frequency | 45~65Hz | |
Safe Power Supply | Range | AC 80~270V 50/60Hz,DC 100~350V |
Consumption | ≤5VA | |
Digital Input | 2 dry contact inputs,Isolation:2kVAC | |
Relay Output | 2 relay outputs,contact rated at AC 5A/250Vor DC 5A/30V,Isolation:2kVAC | |
Analog Output | dc 4~20mA,load ≤350Ω DC 0~5V,load≥20kΩ | |
Communication Port | RS485,Modbus-RTU,2-WIRE,up tp 9600bps | |
Degree of Protection | Front:IP64,Rear :IP20 | |
Operating Temperature | -40℃~70℃(LED),-25℃~70℃(LCD) | |
Storage Temperature | -45℃~85℃(LED),-30℃~80℃(LCD) | |
Relative Humidity | ≤93%RH | |
Insulation | ≥2kVAC | |
Altitude | ≤2500m |
Application
â– Data Acquisition
â– Limit Value Monitoring
â– Measured Value Transducer
â– AC current measurement
â– Panel Meter
â– Limit Value Monitoring
â– Measured Value Transducer
â– AC current measurement
â– Panel Meter
Production Process
Packing & Delivery
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory located in Jiangyin Jiangsu Province.
Q: Does your company provide customized manufacturing?
A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples ? Is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
A: We are factory located in Jiangyin Jiangsu Province.
Q: Does your company provide customized manufacturing?
A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples ? Is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
