Mobile type transformer oil filtration machine
- 1000 per Month
- T/T Credit Card
-
High effective vacuum transformer oil filtration machine
-
High Quality Trailer-Type Transformer Oil Regeneration Plant
-
ZYD Transformer Oil Refinery Machine / transformer Oil Filtration Plant/ transformer oil purifier Equipment
-
Large Capacity ZYD Vacuum Insulation Oil Purifier/Transformer Oil Purification/Dielectric Oil Dehydration Plant
-
Easy Operation Trailer-Type Transformer Oil Treatment Equipment With Large Capacity
-
Hot Selling Trailer-Type Transformer Oil Treatment Plant
Product Description
ZYM mobile insulating/transformer oil filtration
According to field work requirements, the ZYM series trailer-type insulating oil vacuum oil purifier developed by our company has the characteristics of convenient movement, rapid transfer, rainproof, dust-proof, etc., it is especially suitable for oil filtering operations during field power maintenance. ZYM trailer oil purifier is a double-stage vacuum oil purifier, which can quickly and effectively remove moisture, gas (acetylene, hydrogen, methane, etc.) and impurities from the insulating oil, to restore and improve the insulating oil. The filtered oil can effectively ensure the safe and normal operation of power equipment. This machine also has the functions of vacuum drying, vacuum oil injection, and hot oil circulation. It can also be used as a separate vacuum pumping unit to vacuum the transformer and power equipment.
Features:
1. Mobile (trailer) type, completely closed structure, waterproof, dustproof, move easy.
2. Installation of car types, Bridge shock absorber, braking system and steel welding of entire trailer guarantee 60km/h speed.
3. Dealing with unqualified insulating oils, rapidly remove water, gas, particles from oil
4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
Advantages:
Mobile (trailer) type, completely closed structure, waterproof, dustproof, it can move long distance working in field.
Technical Parameters:
|
Index name |
Unit |
ZYM-30 |
ZYM-50 |
ZYM-65 |
ZYM-100 |
ZYM-150 |
||
|
Flow rate |
L/H |
1800 |
3000 |
4000 |
6000 |
9000 |
||
|
Working noise |
dB(A) |
<=65-85 |
||||||
|
Heating power |
Kw |
30 |
30 |
78 |
95 |
110 |
||
|
Total power |
Kw |
35.5 |
37.5 |
87 |
104 |
121 |
||
|
Working vacuum |
MPa |
-0.08--0.099 |
||||||
|
Working pressure |
MPa |
<0.4 |
||||||
|
Temperature range |
C |
20 -80 |
||||||
|
Dielectric strength |
KV |
> 70 |
||||||
|
Water content |
ppm |
< 3 |
||||||
|
Gas content |
% |
< 0.1 |
||||||
|
Particles size |
u |
<1 |
||||||
|
Power supply |
|
380V 50HZ 3Ph (As per user’s option) |
||||||
Our Products List :
ZYD vacuum transformer oil purifier
ZY vacuum transformer/insulating oil purifier
ZYM Mobile Trailer type transformer oil purifier
IIJ-II Insulating/transformer oil dielectric strength tester
TYA Lubricant/hydraulic/turbine oil purifier
JZS Waste engine oil regeneration system
TJ Coalescence and separating oil purifier
TYK Phosphate ester fire-resistant oil purifier
PF Plate pressure oil purifier, Portable oil purifier
NKEE-36 Oil moisture sensor
AD Air dryer for drying electric equipments
TPM Oil water separator
Our Honor and Quality Certificate:
China Famous brand Oil Purifier Company
Golden-supplier for China National Electric power Group
Golden-Supplier for ALSTOM, SIEMENS, SCHNEIDER Company
ISO9001 products quality certificate
CE Products safety certificate
SGS Products local testing report
More than 10 years and 50 countries and districts exporting experience
Our Service:
Our After-sales:
Engineer is available for local installation.
24 months warranty from the delivery time.
24 hours online service question and answer.
More than 10 years experience
Packaging & Shipping:
Packing and delivery way:
Wooden case Suitable for sea transportation and air transportation
