Chinese Manufacture High Speed paper cutting machine best price and quality

Performance and Characteristics
This   febric sheeter (paper cutting machinery,paper cutter) is suitable for cutting big rolling packaging materials such as paper, paper-plastic, multicolor laminated material, etc.  It adopts servo motor (or stepless motor) for controlling constant-length cutting.  It adopts pneumatic, photoelectric sensor for controlling transmission system, with photo, electric, gas together, it has the functions of easy operation, high precision, good stability, low noise. (Pneumatic auto loading device is optional)  This machine has the functions of the frequency converter timing device, auto-matic counting, stop working by alarm and tension adjustment by magnetic powder or manual with friction unit.

Main Technical Parameters



Model

HQJ-800B

HQJ-1100B

HQJ-1300B

Max diameter of material

Φ1400mm

Φ1400mm
Φ1400mm

Max. width of cutting

800mm

1100mm

1300mm

Length of cutting

201200mm

201200mm
201200mm

Precision of fixed length

±0.2mm

±0.2mm
±0.2mm

Speed

10-140times/min

10-140times/min
10-140times/min

Total Power

4kw

4kw

5kw

Weight (approx.)

1200kg

1700kg

2100kg

Overall dimension(LxWxH)

2200×1400×1200(mm)

2200×1700×1200(mm)

2200×1900×1200(mm)
