High Precision YRTS 200 Rotary Table Bearing ,Cylindrical bearing YRT series

Name: High Precision YRTS 200 Rotary Table Bearing ,Cylindrical bearing YRT series
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Products Description

Axial radial bearings YRT product description

BYC Axial radial bearings YRT are axial and radial combined cylindrical roller bearings, including two thrust needle roller bearings and a radial cylindrical roller bearing with the combination of axial and radial preload, For the convenience of transportation and fixing, two or three symmetrical screws are fastened to the two rings in order to prevent rollers and rings generating collisions which influence bearing accuracy.

Products Show

Product Paramenters

Model Number	Boundary Dimensions				Weight
		d	D	H	Weight
		unit： mm				Kg
YRTS200	200	300	30	9.7
YRTS260	260	385	36.5	18.3
YRTS325	325	450	40	25
YRTS395	395	525	42.5	33
YRTS460	460	600	46	45

Model Number	Boundary Dimensions				Weight
		d	D	H	Weight
		unit： mm				Kg
YRTM150	150	240	40	6.2
YRTM180	180	280	43	7.7
YRTM200	200	300	45	9.7
YRTM260	260	385	55	18.3
YRTM325	325	450	60	25
YRTM395	395	525	65	33
YRTM460	460	600	70	45

Plan01

Blister packaging

Plan02

Carton packaging

Plan03

Wooden case packing

Packaging & Shipping.

1. Industrial Neutral Packing,Package as your requirements.

2. Small size Bearings:Plastic vacuum packaging bag+Paper Box/Neutral Carton.

3.Large size Bearings:Plastic film+Brown paper+Roll tape+Wooden Box.

4.Shipping:By air or By sea:DHL/TNT/UPS/EMS etc.

Company Profile

Company Information

Luoyang BoYing Bearing Co., Ltd, (BYC) is a professional manufacturer of high precision bearings,The main products are Crossed roller bearings , YRT Rotary Table Bearings , Crossed Tapered Roller Bearings , Cylindrical Thrust Roller Bearing , Angular Contact Ball Bearings , Thin Section Bearings, Slewing Bearings , Ball Screw Bearings . The accuracy grades are P5, P4, P2, and the size of inner ring are ranging from Φ50mm --- Φ1300mm. Our products are optimal for Robotics, Machine Tools, Rotary Table,medical equipment, measuring instruments ,mainly to replace the imported bearings. Also, we can design , choose and manufacture non-standard precision bearings as customer requested.
