3 Layer Co-extrusion plastic HDPE Pipe make Machine/ Multilayer HDPE Pipe line

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

Extrusion lines of PE series

Model	Pipe Range(mm)	Hauling Speed(m/min)	Total Length(m)	Output Capacity(kg/h)	Total Power(kW)
PE63	∅16-∅63	1.2 - 12	35	80 - 120	110
PE110	∅20-∅110	1.0 - 10	38	150 - 250	163
PE160	∅50-∅160	0.8 - 8	40	200 - 250	169
PE250	∅75-∅250	0.38 - 3.8	42	250 - 350	214
PE315	∅90-∅315	0.3 - 3	44	300 - 350	245
PE450	∅110-∅450	0.2 - 2.0	56	350 - 450	356
PE630	∅250-∅630	0.1 - 1.0	62	700 - 800	563
PE800	∅315-∅800	0.07 - 0.7	68	900 - 1100	740
PE1000	∅400-∅1000	0.06 - 0.6	70	1000 - 1100	800
PE1200	∅500-∅1200	0.05 - 0.5	72	1000 - 1300	927
PE1600	∅710-∅1600	0.04 - 4	74	1200 - 1500	1067

PE650 Water & Gas Supply Pipe Extrusion Line

This PE pipe extrusion line is developed by Xinrong based on the European technology and R&D experience of the plastic machinery. It has the advanced design, reasonable structure, good reliability, the high degree of automation of the complete line.

Extruder with special barrel feeding structure can largely improve extrusion capacity.
Accurate temperature control, good plasticization and automation.
Human-computer interface is easy to operate, convenient and reliable.
Spiral and lattice basket type die head for choice.
Dust-free knife cutter and saw cutter for choice.
Changing some parts of the line can also realize two-layer and multi-layer co-extrusion.
Changing some parts of the line can also produce PP, PB pipes.

Technical Parameters of the PE63 Extrusion Line:

Product matrial	PE
Diameter of the PE pipeline	∅250~630mm
Operating direction	From right to left
Center height	1300mm
Cooling circulating water	22m³/h
Tank volume	30m³
Compressed air	5 m³/h
Total power	563kW
Power supply	3 phase 380V 50Hz
Overall dimension	6600023003000mm

Our showcase projects

	PE630-800 PIPE PRODUCTION LINE Client Khoshnam-e-Khorasan Company was registered in 1996 with the objective of producing Polymer pipes. The client purchased our PE630-800 pipe production line, They are quite satisfied with our equipment after a few days working. Xinrong has right pipe extrusion line and sheet extrusion line solution for your choice. Contact us now for more information. The configuration of PE630-800 pipe extrusion line in Mashhad, Iran Equipment: PE630-800 pipeline Place of use: Iran Using Time: Since December 2014 Processed Material: PE Applications: water pipe
PE-AL-PE Composite Pipe Extrusion Line Client from Turkey who purchased PE Aluminum Composite Pipe Extrusion Line, The client is quite satisfied with our equipment after a few days working. Xinrong has right pipe extrusion line and sheet extrusion line solution for your choice. Contact us now for more information. The configuration of PEX-AL-PEX Composite Pipe Extrusion Line Equipment: PE-AL-PE Composite Pipe Extrusion Line, Place of use: Turkey Using Time: Since November 2013 Processed Material: PE-AL-PE Applications: water pipe
	PE225-600 double wall corrugated pipe line Client from Turkey who purchased PE225-600mm corrugated pipe line, The client is quite satisfied with our equipment after a few days working. Xinrong has right pipe extrusion line and sheet extrusion line solution for your choice. Contact us now for more information. The configuration of PE225-600 pipe extrusion line in turkey Equipment: PE225-600mm double wall corrugated pipe line Place of use: Turkey Using Time: Since November 2013 Processed Material: PE Applications: water pipe
PP-R/Fiberglass Reinforced Composite Pipe Extrusion Line Client from Russia who purchased PPR16-63mm PP-R/Fiberglass Reinforced Composite Pipe Extrusion Line, The client is quite satisfied with our equipment after a few days working. Xinrong has right pipe extrusion line and sheet extrusion line solution for your choice. Contact us now for more information. The configuration of PPR/Fiberglass Reinforced composite pipe extrusion line in Russia Equipment: PP-R/Fiberglass Reinforced Composite Pipe Extrusion Line, Place of use: Russia Using Time: Since November 2015 Processed Material: PPR Applications: water pipe

Company Information

Who we are & What we are capable of

Jiangsu Xinrong Science & Technology Development Co., Ltd was founded in 1996, combines researching, manufacturing, and trading as a whole. The factory area is more than 60,000 square meters; modern office building and workshop take up more than 40,000 square meters and there are more than 200 experienced high-quality staff. With high-speed development, the annual output value grew rapidly by doubling every year since it established in 1996.The company specializes in researching, developing and manufacturing various complete sets of plastic machinery, including plastic pipe extrusion line, profile extrusion line, sheet extrusion line, and plastic recycling machine. Customers accept us because of our product's excellent quality, our team's thoughtful service and-and our company's innovative spirit. The company was rated as Quality Trustworthy Enterprise, High-integrity Enterprise and it acquires ISO Quality Management System Certification, CE Certification, Well-known Enterprise Brand Certification and 3A Credit Rates Certification by the credible third parties. Xinrong sticks to the road of employee-oriented and market-oriented, and takes quality as life, service as the responsibility and technology as the future. We have reached 20 million dollars of the annual output, our machines have been exporting to countries and regions like Russia, Australia, Southeast Asia, Middle East, East Europe, Africa and etc. We sincerely hope to cooperate with friends at home & abroad, and create a prosperous future together.

Here are the reasons why you should choose us

⇒ We have SGS, CE, STS, ISO9001 certificates and own 18 patents(hereby 8 of them are presented down below) which were proved by the State Intellectual Property Office. The ability to innovate and produce machines with high quality at the same time makes us the leading power of the industry in China!

⇒ All the key components of the machines are made by those elite companies like Siemens, Schneider, Bosch and etc. Meanwhile we also produce machine parts with our own facilities, which is a part of our quality control system. It ensures the excellent quality of the machines we manufactured. We own lathes, machining centers, planing-machines and etc.

PLC system & Control panel	Sienmens, Germany
Temperature controller	RKC, Japan
DC speed regulator	Eurotherm, U.K
Inverter	ABB or BOSCH REXROTH
Button, toggle switch	Schneider, France
Contactor	Schneider, France
Air switch	Schneider, France
Intermediate relay	Schneider, France

⇒ We have 20 experienced and skilled senior engineers and 5 of them have the ability to innovate, which is leading the industry in China. Our sales department also has achieved outstanding performance in the domestic&abroad market! We are always ready to offer you the best product and service!

Our Services

How well the service we thought out for you

If you are interested:

Contact us for more detailed info, All the questions and demands will be unambiguously answered and accordingly met.
We highly recommend you come by to check out the machine personally, You would be quickly picked up and well arranged through the visit.

Customized Service:

We could design and build the machine based on your requirements(material, power, key components, etc).
We also offer turnkey project, helping you design factory layout with professional solutions.
The time of manufacturing and shipping can be strictly scheduled by your plan.

After-sale Service:

Our engineers' quick arrival would save you a lot of time to get the machine running, they will install, debug the machine, and train your employees.
We offer remote assistance for problem-shooting to guide you through any questions you come across while using our machines within 12 hours.
We provide one and a half year warranty with free spare components.
