FTTH Handheld OTDR Optical Time Domain Reflectometry 3302s otdr tester
- 1000 per Month
- T/T Credit Card
You May Like
-
mini OTDR fiber optic cable obstacle tester Optical Time Domain Reflectormeter
-
China Mini fiber Optical Meter Reflectometer OTDR 3302S
-
China Expo Cheap Mini Handheld Single Mode and Multimode Pon Gpon Tester 1310nm 1550nm OTDR
-
Optical Time Domain Reflectometry mini OTDR
-
PON OTDR Price 1310 1550 32 38 36dB mini optic otdr tester
-
1310 1490nm Optical Test Equipment FTTH Fiber Optic Mini OTDR
Product Description
3302S Series Multifunctional Photoelectric Integrated Tester
3302S is a series of multi-functional photoelectric integrated testers, suitable for engineering construction and maintenance based on FTTx and access network, testing the breakpoint, length, and loss of the tested fiber, automatic detection of input light, one-button automatic test, 3.5-inch color LCD screen , New plastic-covered shell design, shockproof and drop-resistant, ergonomic feel, compact body, Nine-in-one function, highly integrated OTDR, light eye, stable light source, high-power optical power meter, red light source, network cable sequence proofreading, network cable Length measurement and lighting functions in one, fast detection of fault points, universal connector, FC / SC / ST / LC interchangeable, 600 internal storage in the body, expandable TF card, USB data export, built-in 4000 mAh lithium battery , USB charging, charging treasure power supply at any time, suitable for long-term field work.
| Mini-Pro OTDR | ||
| Model | 3200S | 3200D |
| Wavelength | 1550nm±20nm | 1310nm/1550nm±20nm |
| Fiber Type | G.652 | |
| Dynamic Range | 22dB | 24dB/22dB |
| Event Blind Zone | 3m | |
| ATT Blind Zone | 8m | |
| Test Range | 500m~60km | |
| Pulse Width | 3ns~10us | |
| Ranging accuracy | ±(1m+ Sampling interval +0.005%×Test distance) | |
| Loss accuracy | ±0.05dB/dB | |
| Sampling Points | 16k~128k | |
| Sampling resolution | 0.05m~8m | |
| Reflection accuracy | ±3dB | |
| Data Storage | Internal:≥600;External:TF Card | |
| Laser Safety Level | Class â…¡ | |
