12kw Heat-Transfer Oil Heater Blowing Mold Temperature Controller Unit
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1991
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Industry Water Type PID Mold Temperature ControllerNegotiableMOQ: 1 -
Mini Injection MTC Industry PID Hot Press Machine Mold Temperature ControllerNegotiableMOQ: 1
-
Plastic Crash Machine Soft Plastic Crushing GranulatorNegotiableMOQ: 1
-
50HP Claw Blade Plastic Crusher for Hard Plastic CuttingNegotiableMOQ: 1
-
CE Industrial Plastic Price Pet Bottle Scrap Cutting Crusher MachineNegotiableMOQ: 1
Product Description
Oil Mold Temperature Controller
Standard oil heaters, which are used to heat up the mould and maintain temperature, although they can be used in other similar applications. High temperature oil from the mould is returned to the cooling tank and cooled by indirect cooling. It is then pressurised by the high-pressure pump, sent to the heating tank and finally to the mould with a constant temperature. It can reach a maximum of 200℃.
Product Specifications
Model | XC-TM6KW-O | XC-TM9KW-O | XC-TM12KW-O | XC-TM18KW-O | XC-TM24KW-O | XC-TM36KW-O | |||||
Transfer Medium | Heat Transfer Oil | ||||||||||
Maximum Temperature | 200°C | ||||||||||
Pump (KW) | 0.37 | 0.75 | 0.75 | 1.5 | 1.5 | 2.2 | |||||
Pump Flow (L/min) | 42 | 56 | 56 | 160 | 160 | 315 | |||||
Loading Distance (m) | 28 | 38 | 38 | 27 | 27 | 30 | |||||
Heating Power (KW) | 6 | 9 | 12 | 9*2 | 12*2 | 12*3 | |||||
Inlet and Outlet Diameter | 3/8''x2 | 3/8''x4 | 3/8''x4 | 1''x1 | 1''x1 | 1.5''x1 | |||||
Dimensions (mm) | 730*310*643 | 730*310*643 | 730*310*643 | 830*370*694 | 830*370*694 | 1090*520*983 | |||||
Approx. Net Weight (KG) | 52 | 55 | 55 | 68 | 110 | 113 | |||||
If you want more sizes, please contact us for details
Product Actual Shooting
Product Details
01 LCD controller
▪ Advanced microcomputer LCD controller can display both the actual temperature and set temperature, easy to operate with accuracy ±0.1 Celsius and long continuity and high efficiency.
▪ Digital timing for 24 hours a week to realize automatic operation.
02 Siemens Electric
SIEMENS electrical parts ensures stable running and liability of the machine.
Adopted with high efficiency water pump. It can keep accurate temperature level and it is adaptable for production with precise molding.
Using SUS304 seamless heating wire, stainless steel flange, not easy to burn out, durable.
▪ Using pure copper heat pipe, the heat dissipation effect is better;
▪ The radiator barrel is made of stainless steel, corrosion resistance and long life.
SUS304 stainless steel seamless heating barrel and main pipelines can ensure corrosion-resistant, no leakage and long working lifetime.
Working Principle
Customer Case
Widely used for plastic molding, Die casting of light guide plate, rubber tire,roller, chemical reaction kettle, adhesive industry, plastication and mixing industry etc.
Best Selling
About Us
Company Profile
In 2009, founded by Mr. Fuzhibo with its head quarter in Jiangmen city which known as a famous hometown of many overseas Chinese, Jiangmen Xiecheng Machinery Co., Ltd. has been devoted herself to be an integrated enterprise of R&D, manufacturing and marketing businesses for High-end Industrial Refrigeration Equipment, Rubber and Plastic Moulding Auxiliary Automation Equipment, and also Intelligent Integrated System Solutions.
Authenticated by IS09001, XIECHENG also successfully established the “6+1+C” full dimensional product service system with her own supply chain advantages of combining the six series of products, as Industrial Refrigeration, Mould Temp. Controlling, Material Conveying, Crushing & Recycling, Dehumidifying & Drying, and also Mixing, into central intelligent system solutions as Material Feeding, Air Supply, Water Supply and Power Supply, to fast fitting customers’ specific demands.
